Refer to the pages indicated in () for details.
index to parts and
controls
Front panel
Front panel display window
[1] POWER switch/ indicator
[2] Tape compartment
[3] Remote sensor (7)
[4] & EJECT button
[5] Microphone jack (70)
[6] Headphone jack
MIN/MAX (headphone volume) control
Display window
[9] LANC @ jack
(10 CL (clear/reset) button
ff] LINE IN 2 AUDIO/VIDEO/S-VIDEO jacks (60)
ff] OPERATION PANEL OPEN/CLOSE switch (8)
76 | Additional Information
SR ee eee ee ee
AERA Bt Cee am erate ataten Eaten 15 ip 5
[1] VOICE BOOST indicator (49)
[2] HIE indicator (5)
[3] REMAIN indicator (35)
[4] Linear time counter/Clock
[5] TIME CODE indicator (66)
[6] AM/PM indicator
Tape operation indicator
Tape indicator
[9] TIMER REC indicator
REC (recording) indicator (37)
