File Operations
Chapter 5 Storage and Retrieval of User Setting Data
2 Position the pointer to READ (MS t CAM) and push
on the MENU SEL/ENTER dial.
The camera will be adjusted according to the data of the
reference file.
5-3-6 Reading of the User Gamma
To read out gamma-curve (User Gamma) data that have
been created using CvpFileEditor application software
from the “Memory Stick,” use the <USER GAMMA>
page of the FILE menu.
Insert the “Memory Stick” into the “Memory Stick” slot of
the camera. Position the pointer to READ (MS t CAM)
under USER GAMMA, and push on the MENU SEL/
ENTER dial.
For details on how to use the User Gamma, see “3-11-4
Using the User Gamma” (page 62).
5-3-7 Reading of the User MLUT
To read out a monitor LUT from the “Memory Stick,” use
the <USER GAMMA> page of the FILE menu.
Insert the “Memory Stick” into the “Memory Stick” slot of
the camera. Position the pointer to READ (MS t CAM)
under MONI LUT, and push on the MENU SEL/ENTER
dial.
For details on how to use the User Gamma, see “3-11-4
Using the User Gamma” (page 62).
5-3-8 Storage of the OHB File
Use the <OHB FILE> page of the FILE menu.
1 Execute STANDARD on the <REFERENCE> page of
the FILE menu.
2 Using the MAINTENANCE menu, perform necessary
settings for the items marked with “a” in the “O”
column of the table in “5-2 List of Items Stored in
Files” for the file you wish to store.
3 Call up the <OHB FILE page of the FILE menu,
position the pointer to STORE FILE then push on the
MENU SEL/ENTER dial.
Adjusting the ND offset values
If an ND filter is attached to the matte box, etc., the white
balance may be in variance. In such a case, adjust the ND
offset so that you can retrieve the white balance
compensation value using the ND filter selection page on
the subdisplay.
The offset values ND: 2 to 5 are stored with respect to the
white balance stored for ND: 1 as the reference.
Adjustment procedure
1 Switch the camera to Custom mode, referring to “3-1-
2 Switching of the Basic Operation Modes” (page 33).
2 Execute STANDARD on the <REFERENCE> page of
the FILE menu.
3 Execute AUTO BLACK on the <AUTO SETUP> page
of the MAINTENANCE menu.
4 Connect a waveform monitor via the MONITOR OUT
HD SDI connector 1 or 2 of the camera.
5 Attach the ND filter having the lowest permeability
among the ND filters to be used with this camera, and
shoot a gray-scale chart.
Check that the lighting condition permits a video level
in the range of 560 to 630 mV to be obtained and write
down the current video level.
<USER GAMMA> F04 TOP
USER GAMMA
c
READ (MS
t
CAM)
FILE ID:
CAM CODE
DATE
MONI LUT
READ (MS
t
CAM)
<USER GAMMA> F04 TOP
USER GAMMA
READ (MS
t
CAM)
FILE ID:
CAM CODE
DATE
MONI LUT
c
READ (MS
t
CAM)
<OHB FILE> F06 TOP
c
STORE FILE
