49
Setting the Camera Outputs
Chapter 3 Basic Adjustments and Settings
To compare the playback picture and
camera image
When PBMIX is selected on the MLUT/PBMIX line, the
playback picture and camera image can be displayed on
the same screen with all the outputs.
How this is to be displayed can be set on the <PB MIX
SETTING> page of the USER (OPERATION) menu.
<PB MIX SETTING> page
MIX TYPE
How the picture is to be displayed can be selected.
MIX
When MIX TYPE is set to MIX, how to mix the pictures
can be selected.
WIPE
When MIX TYPE is set to WIPE, how pictures are to be
wiped can be selected.
3-5-3 Outputting Color Bars
The color-bar signal can be output by setting the color-bar
generator built in the camera to ON.
The color-bar generator can be turned ON or OFF on the
<OTHERS 1> page of the USER (MAINTENANCE)
menu.
<OTHERS 1> page
When CAM BARS is set to ON, the color-bar generator is
turned ON, and the color-bar signal is output.
As the HD and SD (VBS) outputs for the viewfinders and
monitors, the format of the color-bar signals can be
independently selected.
HD-BAR (VF MONI)
The format of the color-bar signals sent to the VF1, VF2,
and MONITOR OUT HD SDI connectors can be selected
from among the 10 types.
Setting How to display
MIX The playback picture and camera image are
overlapped. (Default)
WIPE The screen is horizontally or vertically split in
two, and two pictures are displayed
simultaneously.
Item Setting Content
DIRECTION CAM The playback picture is gradually
mixed into the camera image.
(Default)
PB The camera image is gradually
mixed into the playback picture.
MODE Y-MIX The Y signals are mixed. (Default)
WIRE(W) Only the outline components are
mixed and displayed with white
lines.
WIRE(B) Only the outline components are
mixed and displayed with black
lines.
LEVEL 0 to 80% The mix level can be adjusted.
(Default: 80%)
<PB MIX SETTING> U08
MIX TYPE :
B
MIX
MIX
DIRECTION : PB
MODE : Y-MIX
LEVEL : 80%
WIPE
LAYOUT : HOR
PB POSITION : RIGHT
BOUNDARY : 960
Item Setting Content
LAYOUT HOR Horizontally split (Default)
VERT Vertically split
PB
POSITION
RIGHT With HOR, the playback picture
is displayed on the right and the
camera image on the left.
(Default when HOR is selected)
LEFT With HOR, the playback picture
is displayed on the left and the
camera image on the right.
BOTTOM With VERT, the playback picture
is displayed in the lower part
and the camera image in the
upper part. (Default when VERT
is selected)
TOP With VERT, the playback picture
is displayed in the upper part
and the camera image in the
lower part.
BOUNDARY With HOR:
0-1920
With VERT:
0-1080
The boundary position can be
changed. (Default: with HOR:
960, with VERT: 540)
<OTHERS 1> U21
FAN MODE : AUTO1
CAM BARS :
B
ON
HD-BAR(VF/MONI)
BAR 16:9(100%)
SD-BAR
SMPTE
IMAGE INVERT : OFF
IRIS CLOSE : OFF
MONI REMOTE REC : OFF
SMEAR REDUCER : OFF
