Detailed Settings of the Switch Functions
Chapter 3 Basic Adjustments and Settings
3-6-9 Checking the Power Voltage
The settings of the NEAR END and END values to warn
of low voltage of a power supply can be checked on the
<BATTERY ALARM> page of the USER (OPERATION)
menu.
<BATTERY ALARM> page
This page is intended for display only. You can only switch
the type. If you want to change the values, use the <BATT
ALARM SET> page of the MAINTENANCE menu.
3-7 Detailed Settings of
the Switch Functions
By using the <SWITCH ASSIGN> page of the USER
(OPERATION) menu displayed on the viewfinder/monitor
screen, the operation mode of the MENU SEL/ENTER
dial in addition to function assignment to the assignable
buttons/switch that can also be made on the subdisplay.
<SWITCH ASSIGN> page
Assigning functions to the assignable
buttons/switch
When you position the pointer to any of the ASSIGN SW1
to ASSIGN SW4 lines and push on the MENU SEL/
ENTER dial, the subpage to set the corresponding button/
switch is displayed.
You can assign the same functions as those when you
operate the subdisplay.
For the assignable functions, see “3-2-11 Allocation of
Functions to the Assignable Buttons and Switch” (page
41).
Setting subpage for assignable button 1
The setting subpages for button 2 and 3 have the same
layout as that for button 1.
Menu item Indication
DC IN (24V) Voltage of the 24-V power
TYPE Select the type of the 24-V power source.
NEAR END NEAR END value specified for the 24-V
power source of the selected type
END END value specified for the 24-V power
source of the selected type
DC IN (12V) Voltage of the 12-V power
TYPE Select the type of the 12-V power source.
NEAR END NEAR END value specified for the 12-V
power source of the selected type
END END value specified for the 12-V power
source of the selected type
<BATTERY ALARM> U15
DC IN (24V) 24.2V
TYPE:
B
AC ADP
NEAR END : (22.2)
END : (21.6)
DC IN (12V) 12.8V
TYPE:
AC ADP
NEAR END : (11.1)
END : (10.8)
<SWITCH ASSIGN> U13
ASSIGN SW1 :
B
OFF
ASSIGN SW2 : OFF
ASSIGN SW3 : OFF
ASSIGN SW4 : OFF
RE_ROTATION: STD
ASSIGN SW1 ESC
B
OFF
ND
REC REVIEW
PB(VF)
VF MLUT
MONI MLUT
FAN MODE
GAIN -9/-18dB
