42
Basic Settings with the Subdisplay
Chapter 3 Basic Adjustments and Settings
Functions that can be allocated to assignable
switch 4
Even if AWB is allocated to assignable switch 4, AWB
does not function in Cine-EI mode and Cine mode.
Assignable buttons 1/2 setting page
The functions of buttons 1 and 2 can be assigned on the
first and second line, respectively.
Assignable button 3/switch 4 setting page
The functions of button 3 and switch 4 can be assigned on
the first and second line, respectively.
3-2-12 Brightness Adjustment of the
Subdisplay
The brightness of the subdisplay can be adjusted, in eight
levels.
Subdisplay brightness adjustment page
The higher the value, the brighter the display.
3-2-13 Selection of Gamma Tables
In Cine mode or Custom mode, the gamma curves can be
selected on the gamma table selection page of the
subdisplay.
The page is for display only and not operative in Cine-EI
mode.
Gamma table selection page
Select the gamma table on the first line (STANDARD,
HYPER, SPECIAL, or USER) and the gamma curve on
the second line.
For details on the available gamma curves, see “3-11
Selecting the Gamma” on page 60.
3-2-14 Selection of Color Spaces
In Cine mode or Custom mode, color reproducibility can
be selected on the color space selection page of the
subdisplay.
The page is for display only and not operative in Cine-EI
mode.
Color space selection page
Select the color space mode (S-GAMUT, F900, F900R, or
DCDM REF PJ) on the second line.
For information on color space modes, see “3-1-2
Switching of the Basic Operation Modes” (page 33) and
“Color Space According to the COLOR SPACE Settings”
(page 143).
PB(VF) The video signals being played back on
the SRW-1 are output to the viewfinder.
VF MLUT ON/OFF of the monitor LUT for the
viewfinder
MONI MLUT ON/OFF of the monitor LUT for external
monitors
FAN MODE Switching of Fan Operation mode
GAIN –9/–18 dB If the picture becomes too bright when
you set the lens iris to its open end to
assist the focus adjustment, the electric
gain can be temporarily decreased to
resume the proper picture level by using
this function.
Each push on the assignable button
changes the setting in the sequence of
OFF, –9 dB, –18 dB, OFF, and so on.
Notes
• The gain-decreased condition is
automatically released in approx. 1
minute.
• Do not perform recording in the
condition where the gain is decreased
with this function.
OFF None
Menu
indication
Function
AWB Automatic white balance adjustment
BARS Color-bar indication
TEST1 Test signal output
OFF None
Note
Menu
indication
Function
AS1:OFF
AS2:OFF
AS3:OFF
AS4:OFF
BRIGHT:1
GAMMA:STANDARD
5 ITU-R709
COLOR SPACE
F900
