57
Setting the Gain
Chapter 3 Basic Adjustments and Settings
Setting subpage for assignable switch 4
Position the pointer to the function to be assigned and push
on the MENU SEL/ENTER dial.
Setting the operation mode of the MENU
SEL/ENTER dial
You can reverse the operation corresponding to the
directions of rotation of the MENU SEL/ENTER dial on
the camera head and that on the assistant panel.
3-8 Setting the Gain
If the gain of the video amplifier of this camera is to be
switched using the gain switch of the RM-B150 Remote
Control Unit, the gain values for the corresponding switch
positions must be specified in advance.
Use the <GAIN ASSIGN> page of the USER
(OPERATION) menu.
<GAIN ASSIGN> page
Any of –6, –3, 0, 3, 6, 9, or 12 dB can be set for each of the
L, M, and H positions, in any sequence.
Setting Operation
STD (default) Clockwise rotation moves the pointer/
cursor down or increases values on a
menu/subdisplay page.
RVS Clockwise rotation moves the pointer/
cursor up or decreases values on a menu/
subdisplay page.
ASSIGN SW4 ESC
B
OFF
AWB
BARS
TEST1
Menu item Setting
GAIN [L] Gain value corresponding to the L position
of the gain switch
GAIN [M] Gain value corresponding to the M position
of the gain switch
GAIN [H] Gain value corresponding to the H position
of the gain switch
<GAIN ASSIGN> U14
GAIN [L]:
B
0 dB
[M]: 6 dB
[H]: 12 dB
To Next Page
