Sony F35 - Specifications

137
Specifications
Appendixes
Specifications
Camera Head
General
Power requirements
DC 10.5 to 17 V
Power consumption
Approx. 56 W with 23.98 PsF (not
including lens, viewfinder)
Operating temperature
0°C to +40°C (32°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Mass Approx. 5 kg (11 lb) (camera head only)
Dimensions See page 139.
Imagers
Imagers Super 35-mm RGB color CCD array
Method 1CCD
Aspect ratio 16:9
Effective resolution
R, G, B individualy
1920 (horizontal) × 1080 (vertical)
Electrical characteristics
Sensitivity (at 2000 lx with 89.9% reflectivity)
T9 with 29.97 PsF (with <BASE
SETTING>D-RANGE: NORMAL)
T10 with 29.97 PsF (with <BASE
SETTING>D-RANGE: EXTEND)
ISO sensitivity ISO 340 (with <BASE SETTING>
D-RANGE: NORMAL)
ISO 450 (with <BASE SETTING>
D-RANGE: EXTEND)
Registration 0.02% for total area (not including lens
distortion)
Geometric distortion
Negligible (not including lens
distortion)
Horizontal resolution
1000 TV lines (at center of screen)
5% or higher modulation
Optical system specifications
Lens mount 54-mm PL Mount
Flange focal length
52.00 mm (±0.15 mm adjustable)
• “Memory Stick”, and “MagicGate Memory
Stick” are trademarks of Sony Corporation.
• “Memory Stick Duo” and are
trademarks of Sony Corporation.
• “Memory Stick PRO” and are
trademarks of Sony Corporation.
• “Memory Stick PRO Duo” and are
trademarks of Sony Corporation.
• “Memory Stick-ROM” and are
trademarks of Sony Corporation.
• “MagicGate Memory Stick” is trademark of Sony
Corporation.
• “MagicGate” and are trademarks of Sony
Corporation.
