98
Menu List
Chapter 4 Menu Configuration and Detailed Settings
<USER GAMMA> F04
[F02]
USER GAMMA To load user gamma tables
from a “Memory Stick”
READ (MStCAM) Execute by ENTER.
FILE ID Max.14 characters Display only
CAM CODE F35 Camera code Display only
DATE Display only
MONI LUT To load monitor LUT from a
“Memory Stick”
READ (MStCAM) Execute by ENTER.
<LENS FILE> F05
[F03]
STORE FILE
1)
Execute by ENTER.
No. 1 1 to 32
NAME No Offset
CENTER
1)
To set and store the center
marker position:
H: Increasing the value
moves it to the right.
V: Increasing the value
moves it downwards.
H
1)
0 –96 to 95
V
1)
0 –54 to 53
STORE
1)
Execute by ENTER.
WHITE R/G/B ON ON, OFF To turn the WHITE R/G/B
compensation by the lens
file on or off.
For color balance
compensation against lens
dispersion. As G can be
compensated in addition to
R and B, compensation of
dispersion of sensitivity is
also possible.
LENS MS READ/
WRITE
Execute by ENTER. To jump to the subpage
<LENS FILE>
subpage
READ (MStCAM) Execute by ENTER. To load a lens file from a
“Memory Stick” (max. 32
files)
WRITE (CAMtMS) Execute by ENTER. To write the current settings
of the lens file items as a
lens file to a “Memory Stick”
FILE ID Max.14 characters Enter a comment for the lens
file to be written to a
“Memory Stick.”
See “Specifying a character
string” (page 68).
CAM CODE F35 Camera code Display only
DATE Display only
<OHB FILE> F06
[ - - ]
STORE FILE Execute by ENTER. To store the offset values of
the items specific to the
CCD (No repeated store
operation is necessary even
if the CCD is reattached.)
<FILE PRESET 1> F07
[F04]
OPERATOR FILE Execute by ENTER. To resume the factory-set
status
USER MENU Execute by ENTER. To resume the factory-set
status
M. S. FORMAT Execute by ENTER. To initialize a “Memory Stick”
FILE menu
Page title No. Item Default Settings Remarks
