Sony GN3UN - SECTION 5 DIAGRAMS; Circuit Board Location

151
5-1.CIRCUIT BOARD LOCATION
1. 32”
2. 40”
3 .49”
SWITCH
UNIT
UNIVERSAL
SIL-TU
BLM_MOUNT
CARD,
WIRELESS LAN
LK1_MOUNT
HKT MOUNT
SWITCH
UNIT
UNIVERSAL
SIL-TU
BLM_MOUNT
CARD,
WIRELESS LAN
LK1_MOUNT
HKT MOUNT
SWITCH
UNIT
UNIVERSAL
SIL-TU
BLM_MOUNT
CARD,
WIRELESS LAN
LK1_MOUNT
HKT MOUNT
SECTION 5
DIAGRAMS
NOTE :
• This is for KM models.
• For KL and Woofer models , please refer to Unique
manual for each segment.
