Sony GN3UN - Overall DCDC Converter Check; DC-DC Converter Reference Points

DC-DC Converter Reference Points
IC Ref Voltage supply Output ref. Enable pin Enable source Fuse Vcc ref.
IC6000
+1.1V C6014 - - - -
+1.2V C6003 - - - -
+1.5V C6023 - - - -
+1.8V_EMMC C6065 - - - -
+1.8V C6006 - - - -
IC6001 +STBY_5V C6041 R6040 MAIN_RST F6001 C6029
IC6002 +12V LNB C6054 R6051/R6052 3.3V_EN/PANEL_PWR F6000 C6047
IC6004 +3.3V_STBY C6090 R6100
19.5V_O
F6002 -
Q6005 +3.3V Q6005 Q6005 #pin1 Q6004 pin#1 - -
3g.3.0 Overall DCDC Converter Check
88
