Sony GN3UN - Panel I2 C Error

3d.1 : 5x Blinking – Panel I2C Error
BLM Board (General Checking)
START
TV set is OK now
NG Symptom:
O-Cell/Panel Issue NG
TV Boots Up Normally?
* O-Cell or Panel
Module replacement
depends on service
capabilities
Reinsert LVDS Flat
Flexible Cable (FFC) at B-Board and
Panel Side. Make sure FFC is fully
inserted.
5 Times Blinking happen?
YES
No
Replace LVDS Flat Flexible
Cable (FFC)
TV set is OK now
NG Symptom:
Incorrect FFC Insertion
5 Times Blinking happen?
YES
No
TV set is OK now
NG Symptom:
LVDS Cable NG
Replace B-Board
5 Times Blinking happen?
YES
No
Replace
O-Cell* or Panel Module*
Is 3V -3.33V available?
YES
NO
Refer to Panel I2C
Manual Checking
TV set is OK now
NG Symptom:
B-Board Issue NG
Yes
31
