3f.7.7 HDMI No picture– Checking Point
3f.7.7 HDMI – No picture
HDMI 2
(CN4000)
HDMI 1
(CN4001)
Zoom
Pin 19
Pin 1
L4002
L4003
RB400
2
RB400
3
RB400
0
RB400
1
L4000
L4001
RB400
5
RB400
4
R4005
R4007 R4001
R4004
R4010
R4008
R4009
R4011
VR400
6
VR400
7
R4015
R4018
70
