Sony GN3UN - Table of Contents

Section Title Page
1. SAFETY NOTES 5
2. SELF DIAGNOSTIC FUNCTION 14
3. TROUBLE SHOOTING 17
4. SERVICE ADJUSTMENTS
123
5. DIAGRAMS
151
4
TABLE OF CONTENTS
Please refer Service Manual – Unique for below information :
-Safety Warnings
-Wire Dressing
-Circuit Board Location
-Disassembly and Exploded View.
Note: Pictures provided in this Service Manual might have slight difference from the
actual sets.
Please refer to GN3UN Service Procedure for Panel , Board and Software Change /
Upgrade Manual , part number 9-888-724-0x in TISS .
