Board Name Board PWB (B side) Detail
BLM board
(A side)
(3.3V)
CL1001
(1.8V)
CL1002
(12V)
CL1007
BLM board
(A side)
3f.3.1 No Picture Tuner (Analog, Digital, Satellite) – Checking Point
3f.3.1 No Picture Tuner (Analog, Digital, Satellite)
Area
Detail
CL1002
(1.8V)
CL1001
(3.3V)
F1000
CL1007
(12V)
