3f.3.1 No Picture Tuner (Analog, Digital, Satellite) – Checking Point
3f.3.2 For Analog Tuning Failed (All Destination)
Board Name Board PWB (A side) Detail
BLM board
(A side)
(IFOUTN1)
FB1000
C1011
C1027
R1055
R1057
(IFOUTP1)
FB1001
R1083
C1012
C1028
R1056
C1028
C1011
FB1000
R1055
C1027
C1012
FB1001
R1083
R1056
R1057
