3f.6 CI Slot – Cannot Play / No picture / No Sound – Checking Point
3f.6 CI Slot
CI Slot (B-board Checking) – Checking 5V Points [1/3]
Board
Name
Board PWB (A side) Detail
BLM
CI 5V at PIN
17/18/51/52
59
