HBD-E2100/E3100/E3200/E4100/E6100
26
8. Diag (MIC Input Test)
This screen performs MIC input test.
Note: Not used for the servicing.
9. Diag (HDMI Input Test)
This screen performs HDMI input test.
Note: Not used for the servicing.
10. Diag (Transcoder Test)
Note: Not used for the servicing.
11. Diag (Bluetooth Device Test)
This screen performs Bluetooth Device Test.
Screen 1: Select Bluetooth Device Test Category
Operation:
[<]/[,] Selects the category
[m]/[ ] Activate the selected category
[RETURN] Returns to the service top menu
Screen 2: Select Bluetooth Device Test
Operation:
[1] Bluetooth Enable
[2] Bluetooth Disable
[3] Write Bluetooth device address to Registry.
[4] Bluetooth Inquiry Test
[M]/[m] Selects Device
[ ] Activate and Start Test
[RETURN] Returns to the selection of test category
Screen 2: Select [1] Bluetooth Enable
• Viewing the Status display, if
Successful: “Bluetooth Enable Successful!”
Fail: “Bluetooth Enable Fail!”
Screen 3 : Select [2] Bluetooth Disable
• Viewing the Status display, if
Successful: “Bluetooth Disable Successful!”
Fail: “Bluetooth Disable Fail!”
Screen 4 : Select [3] Store Bluetooth device address to
Registry
Display will show : Bluetooth device address : “xx:xx:xx:xx:xx:xx”
• Viewing the Status display, if
Successful: “Write Successful!”
Fail: “Write Fail!”
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Stop Display RSSI Value
[4] Start Ping Test
RSSI Value : 60
HELP: [UP][DOWN][ENT][RET]
(Screen 3)
(Screen 4)
Diag

Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Stop Display RSSI Value
[4] Start Ping Test
Ping To : 192.168.1.10
PING 192.168.1.10 OK!
HELP: [UP][DOWN][ENT][RET]
(Screen 5)

Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
CERT : NO-ENCRYPT
WEPKEY : abcdef1234
PMK : ABCDE12345
SSID : SONY-Test-R
IPADDR : 192.168.1.100
NETMASK: 255.255.255.0
BROADCAST : 192.168.1.10
Status : Connected!
HELP: [UP][DOWN][ENT][RET]

Diag
Category: Wireless LAN Test
 Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
Serial : 200912313165535
Hard : 22
Mac : 00:01:36:23:FD:CF
HELP: [UP][DOWN][ENT][RET]
(Screen 1)
(Screen 2)
Diag
Ver. 1.5
