10
CD TRAY
1 two screws
2 top cabinet
1 two screws
4 screw
6 screw
7 bracket
5 bracket
8 CD tray
3 wire (flat type) (5core
)
(CN06)
DECODE BOARD
4 three screws
6 DECODE board
1 wire (flat type) (5core)
(CN706)
2 wire (flat type) (15core)
(CN701)
3 connector
(CN707)
5 connector
(CN702)
