43
SECTION 6
ELECTRICAL PARTS LIST
AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4473-607-A AMP BOARD, COMPLETE (US)
************************
* 1-533-213-31 HOLDER, FUSE
7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
< CAPACITOR >
C400 1-161-494-00 CERAMIC 0.022uF 25V
C401 1-109-953-11 ELECT 2.2uF 20% 50V
C402 1-109-953-11 ELECT 2.2uF 20% 50V
C403 1-162-292-31 CERAMIC 680PF 10% 50V
C404 1-162-292-31 CERAMIC 680PF 10% 50V
C405 1-104-664-11 ELECT 47uF 20% 25V
C406 1-104-664-11 ELECT 47uF 20% 25V
C407 1-126-964-11 ELECT 10uF 20% 50V
C408 1-126-964-11 ELECT 10uF 20% 50V
C409 1-164-159-11 CERAMIC 0.1uF 50V
C410 1-126-964-11 ELECT 10uF 20% 50V
C411 1-126-964-11 ELECT 10uF 20% 50V
C413 1-162-199-31 CERAMIC 10PF 5% 50V
C414 1-162-199-31 CERAMIC 10PF 5% 50V
C415 1-130-777-00 MYLAR 0.1uF 5% 100V
C416 1-130-777-00 MYLAR 0.1uF 5% 100V
C417 1-161-494-00 CERAMIC 0.022uF 25V
C418 1-161-494-00 CERAMIC 0.022uF 25V
C419 1-107-714-11 ELECT 10uF 20% 50V
C421 1-126-933-11 ELECT 100uF 20% 16V
C422 1-126-961-11 ELECT 2.2uF 20% 50V
C427 1-164-159-11 CERAMIC 0.1uF 50V
C428 1-109-953-11 ELECT 2.2uF 20% 50V
C429 1-162-286-31 CERAMIC 220PF 10% 50V
C430 1-162-286-31 CERAMIC 220PF 10% 50V
C431 1-161-494-00 CERAMIC 0.022uF 25V
C432 1-161-494-00 CERAMIC 0.022uF 25V
C433 1-126-941-11 ELECT 470uF 20% 25V
C435 1-161-494-00 CERAMIC 0.022uF 25V
C437 1-126-933-11 ELECT 100uF 20% 16V
C438 1-126-933-11 ELECT 100uF 20% 16V
C439 1-161-494-00 CERAMIC 0.022uF 25V
C441 1-161-494-00 CERAMIC 0.022uF 25V
C442 1-161-494-00 CERAMIC 0.022uF 25V
C450 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
CN701 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D401 8-719-911-19 DIODE 1SS133T-72
D402 8-719-911-19 DIODE 1SS133T-72
D403 8-719-911-19 DIODE 1SS133T-72
D404 8-719-911-19 DIODE 1SS133T-72
D405 8-719-911-19 DIODE 1SS133T-72
D407 8-719-200-02 DIODE 1N4002
D408 8-719-200-02 DIODE 1N4002
D409 8-719-911-19 DIODE 1SS133T-72
D410 8-719-010-44 DIODE UZ-6.2BS
D411 8-719-200-02 DIODE 1N4002
D412 8-719-200-02 DIODE 1N4002
< FUSE >
0 F401 1-576-108-11 FUSE (4A/125V) (US, Canadian)
< IC >
IC401 8-749-016-94 IC STK402-090S
< TERMINAL >
JK401 1-694-604-11 TERMINAL, SPEAKER (4P) (SPEAKER)
< TRANSISTOR >
Q401 8-729-231-55 TRANSISTOR 2SC2878-A
Q402 8-729-231-55 TRANSISTOR 2SC2878-A
Q403 8-729-184-53 TRANSISTOR 2SC1841-EA
Q404 8-729-184-53 TRANSISTOR 2SC1841-EA
Q407 8-729-231-55 TRANSISTOR 2SC2878-A
Q408 8-729-231-55 TRANSISTOR 2SC2878-A
Q409 8-729-207-35 FET 2SJ105-Y
Q410 8-729-142-46 TRANSISTOR 2SC2001-L
Q411 8-729-184-53 TRANSISTOR 2SC1841-EA
Q412 8-729-119-76 TRANSISTOR 2SA733-P
Q413 8-729-142-46 TRANSISTOR 2SC2001-L
Q414 8-729-142-46 TRANSISTOR 2SC2001-L
Q415 8-729-194-57 TRANSISTOR 2SC945TP-P
Q416 8-729-140-96 TRANSISTOR 2SC2060-R
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
