Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
* CN06 1-568-824-11 SOCKET, CONNECTOR 5P
**************************************************************
A-4473-602-A SENSOR BOARD, COMPLETE
************************
< CAPACITOR >
C644 1-126-964-11 ELECT 10uF 20% 50V
< IC >
RM601 8-749-013-84 IC SPS-447-1
**************************************************************
A-4473-612-A SOCKET BOARD, COMPLETE
************************
< CAPACITOR >
C710A 1-164-159-11 CERAMIC 0.1uF 50V
< IC>
PH701 8-749-923-04 IC TOTX178A
**************************************************************
1-674-788-11 SW A BOARD
***********
< SWITCH >
S04 1-771-169-11 SWITCH (TURN TABLE OPERATION DETECT)
**************************************************************
1-674-789-11 SW B BOARD
***********
S03 1-771-169-11 SWITCH (TURN TABLE POSITION DETECT)
**************************************************************
1-674-790-11 SW C BOARD
***********
S02 1-571-300-31 SWITCH, ROTARY (OPEN/CLOSE DETECT)
**************************************************************
1-674-791-11 SW D BOARD
***********
S01 1-571-300-31 SWITCH, ROTARY
(OPTICAL PICK-UP UP/DOWN DETECT)
**************************************************************
A-4473-606-A TR BOARD, COMPLETE
********************
< CAPACITOR >
C840 1-161-494-00 CERAMIC 0.022uF 25V
C841 1-161-494-00 CERAMIC 0.022uF 25V
< TRANSISTOR >
Q801 8-729-822-89 TRANSISTOR 2SD1667-R
Q802 8-729-822-89 TRANSISTOR 2SD1667-R
**************************************************************
MOTOR SENSOR SOCKET SW A SW B SW C SW D TR
MISCELLANEOUS
**************
69 1-769-273-11 WIRE (FLAT TYPE) (22 CORE)
72 1-772-163-11 DECK, MECH
151 1-769-856-11 WIRE (FLAT TYPE) (5 CORE)
0 205 1-796-266-11 OPTICAL PICK-UP
253 1-792-850-11 WIRE (FLAT TYPE) (16 CORE)
262 1-783-531-51 CORD, POWER (US, Canadian)
CN705 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
M101 1-541-352-12 MOTOR (SPINDLE)
M102 1-541-353-12 MOTOR (SLED)
M103 X-4948-765-1 MOTOR ASSY (TURN TABLE)
M104 X-4948-766-1 MOTOR ASSY (A) (TRAY)
S05 1-572-085-11 SWITCH, LEAF (LIMIT)
0 T001 1-435-611-11 TRANSFORMER, POWER (US)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-246-19 SCREW +KTP 3X8 TYPE2 SLIT
#3 7-685-903-31 SCREW +PTPWH 3X10 (TYPE2)
#4 7-682-904-11 SCREW +PWH 4X8
#5 7-685-647-79 SCREW +BVTP 3X10 TYPE2 TT(B)
#6 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#8 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#9 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-685-902-21 SCREW +PTPWH 2.6X8 (TYPE2)
#12 7-624-118-01 RING, RETAINING E-2.5
#13 7-685-903-21 SCREW +PTPWH 3X8 (TYPE2)
#14 7-685-535-19 SCREW +BTP 2.6X10 TYPE2 N-S
#15 7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
#16 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
#17 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#18 7-685-647-14 SCREW +BVTP 3X10 TYPE2 N-S
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
