Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-BX77DBi
52
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-857-11 METAL CHIP 1M 5% 1/10W
R155 1-216-805-11 METAL CHIP 47 5% 1/10W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-91 SHORT CHIP 0
R202 1-216-295-91 SHORT CHIP 0
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-809-11 METAL CHIP 100 5% 1/10W
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R206 1-216-809-11 METAL CHIP 100 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-809-11 METAL CHIP 100 5% 1/10W
R209 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-845-11 METAL CHIP 100K 5% 1/10W
R219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-845-11 METAL CHIP 100K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R304 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R414 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VIBRATOR >
X102 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
************************************************************
A-1507-152-A DAB BOARD, COMPLETE
********************
< CAPACITOR >
C802 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C803 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C804 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C805 1-125-972-91 ELECT 100uF 20% 16V
C806 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C807 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C808 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C811 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C812 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C813 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C814 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C817 1-126-160-11 ELECT 1uF 20% 50V
C818 1-126-160-11 ELECT 1uF 20% 50V
C820 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C821 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C823 1-126-176-11 ELECT 220uF 20% 10V
C824 1-126-176-11 ELECT 220uF 20% 10V
C825 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C827 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C828 1-126-929-11 ELECT 4700uF 20% 10V
C833 1-126-160-11 ELECT 1uF 20% 50V
C834 1-126-160-11 ELECT 1uF 20% 50V
< CONNECTOR >
CN800 1-821-719-11 P.W.B CONNECTOR 30P
CN801 1-568-854-11 CONNECTOR, FFC 11P
< DIODE >
D804 6-501-582-01 DIODE 1N4002-B5
D805 6-501-582-01 DIODE 1N4002-B5
< JUMPER RESISTOR >
FB801 1-216-864-11 SHORT CHIP 0
FB802 1-216-864-11 SHORT CHIP 0
< IC >
IC801 6-702-302-01 IC TK11133CSCL-G
IC802 6-711-033-01 IC TK681
12AS2G0L-C
IC803 8-759-100-96 IC uPC4558G2
< RESISTOR >
R800 1-216-833-11 METAL CHIP 10K 5% 1/10W
R801 1-216-841-11 METAL CHIP 47K 5% 1/10W
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R803 1-216-864-11 SHORT CHIP 0
R804 1-216-864-11 SHORT CHIP 0
R805 1-216-837-11 METAL CHIP 22K 5% 1/10W
R806 1-216-837-11 METAL CHIP 22K 5% 1/10W
R807 1-216-837-11 METAL CHIP 22K 5% 1/10W
R808 1-216-837-11 METAL CHIP 22K 5% 1/10W
R809 1-216-864-11 SHORT CHIP 0
R810 1-216-837-11 METAL CHIP 22K 5% 1/10W
R811 1-216-837-11 METAL CHIP 22K 5% 1/10W
R813 1-216-837-11 METAL CHIP 22K 5% 1/10W
R814 1-216-837-11 METAL CHIP 22K 5% 1/10W
R815 1-216-821-11 METAL CHIP 1K 5% 1/10W
R816 1-216-821-11 METAL CHIP 1K 5% 1/10W
R817 1-216-841-11 METAL CHIP 47K 5% 1/10W
R818 1-216-841-11 METAL CHIP 47K 5% 1/10W
R825 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R826 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R830 1-216-809-11 METAL CHIP 100 5% 1/10W
R832 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
HP BOARD
*********
< CAPACITOR >
C131 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C231 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C531 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C581 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-566-822-51 JACK (AUDIO)
J500 1-815-629-21 JACK (PHONES)
CD DAB HP
