Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-BX77DBi
5353
< RESISTOR >
R132 1-216-841-11 METAL CHIP 47K 5% 1/10W
R133 1-216-821-11 METAL CHIP 1K 5% 1/10W
R232 1-216-841-11 METAL CHIP 47K 5% 1/10W
R233 1-216-821-11 METAL CHIP 1K 5% 1/10W
R531 1-216-817-11 METAL CHIP 470 5% 1/10W
R532 1-216-817-11 METAL CHIP 470 5% 1/10W
R533 1-216-817-11 METAL CHIP 470 5% 1/10W
R534 1-216-817-11 METAL CHIP 470 5% 1/10W
R535 1-216-817-11 METAL CHIP 470 5% 1/10W
R536 1-216-817-11 METAL CHIP 470 5% 1/10W
R537 1-216-833-11 METAL CHIP 10K 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R539 1-216-833-11 METAL CHIP 10K 5% 1/10W
R540 1-216-833-11 METAL CHIP 10K 5% 1/10W
R581 1-216-817-11 METAL CHIP 470 5% 1/10W
R582 1-216-817-11 METAL CHIP 470 5% 1/10W
R583 1-216-817-11 METAL CHIP 470 5% 1/10W
R584 1-216-817-11 METAL CHIP 470 5% 1/10W
R585 1-216-817-11 METAL CHIP 470 5% 1/10W
R586 1-216-817-11 METAL CHIP 470 5% 1/10W
R587 1-216-833-11 METAL CHIP 10K 5% 1/10W
R588 1-216-833-11 METAL CHIP 10K 5% 1/10W
R589 1-216-833-11 METAL CHIP 10K 5% 1/10W
R590 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
A-1466-251-A IP BOARD, COMPLETE
******************
< CAPACITOR >
C101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C108 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C109 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C114 1-128-004-11 ELECT CHIP 10uF 20% 16V
C115 1-128-004-11 ELECT CHIP 10uF 20% 16V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C120 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-766-382-21 PIN, CONNECTOR (1.5mm) (SMD) 10P
CN102 1-820-701-11 PIN, CONNECTOR 30P (iPod)
< DIODE >
D102 8-719-071-34 DIODE RB521S-30-TE61
D104 8-719-071-34 DIODE RB521S-30-TE61
< IC >
IC101 6-807-873-01 IC R5F21246SN060FP
IC102 6-702-302-01 IC TK11
133CSCL-G
IC103 6-707-593-01 IC PST3641UL
< TRANSISTOR >
Q102 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q103
6-551-750-01 TRANSISTOR 2SD2114KT146W
Q104 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q105 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q106 8-729-028-73 TRANSISTOR DTA114EUA-T106
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R107 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R108 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R109 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R110 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R111 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R112 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R113 1-218-907-11 METAL CHIP 330K 0.5% 1/10W
R114 1-216-809-11 METAL CHIP 100 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-839-11 METAL CHIP 33K 5% 1/10W
R118 1-216-864-11 SHORT CHIP 0
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R132 1-216-833-11 METAL CHIP 10K 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-809-11 METAL CHIP 100 5% 1/10W
R137 1-216-809-11 METAL CHIP 100 5% 1/10W
R138 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-845-11 METAL CHIP 100K 5% 1/10W
R140 1-216-845-11 METAL CHIP 100K 5% 1/10W
R141 1-216-821-11 METAL CHIP 1K 5% 1/10W
R142 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-821-11 METAL CHIP 1K 5% 1/10W
R144 1-216-821-11 METAL CHIP 1K 5% 1/10W
R146 1-216-833-11 METAL CHIP 10K 5% 1/10W
R147 1-216-845-11 METAL CHIP 100K 5% 1/10W
R148 1-216-845-11 METAL CHIP 100K 5% 1/10W
R149 1-216-809-11 METAL CHIP 100 5% 1/10W
R150 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-795-375-11 VIBRATOR, CERAMIC (20MHz)
************************************************************
A-1775-214-A MAIN BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C104 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C108 1-126-961-11 ELECT 2.2uF 20% 50V
C109 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C111 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C113 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C114 1-126-960-11 ELECT 1uF 20% 50V
C116 1-126-963-11 ELECT 4.7uF 20% 50V
C117 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C119 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
HP IP MAIN
Note: Refer to supplement-1 for the IP board of the following serial No. or larger.
AEP model : Serial No. 5100859 or larger
UK model : Serial No. 6123118 or larger
Ver. 1.1
To Next Page
