Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-BX77DBi
5757
R611 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R700 1-216-809-11 METAL CHIP 100 5% 1/10W
R701 1-216-809-11 METAL CHIP 100 5% 1/10W
R702 1-216-809-11 METAL CHIP 100 5% 1/10W
R703 1-216-809-11 METAL CHIP 100 5% 1/10W
R704 1-216-809-11 METAL CHIP 100 5% 1/10W
R705 1-216-809-11 METAL CHIP 100 5% 1/10W
R706 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-216-809-11 METAL CHIP 100 5% 1/10W
R709 1-216-833-11 METAL CHIP 10K 5% 1/10W
R711 1-216-849-11 METAL CHIP 220K 5% 1/10W
R713 1-216-864-11 SHORT CHIP 0
R716 1-216-864-11 SHORT CHIP 0
R717 1-216-833-11 METAL CHIP 10K 5% 1/10W
R718 1-216-809-11 METAL CHIP 100 5% 1/10W
R719 1-216-809-11 METAL CHIP 100 5% 1/10W
R720 1-216-841-11 METAL CHIP 47K 5% 1/10W
R722 1-216-809-11 METAL CHIP 100 5% 1/10W
R724 1-216-809-11 METAL CHIP 100 5% 1/10W
R725 1-216-809-11 METAL CHIP 100 5% 1/10W
R726 1-216-809-11 METAL CHIP 100 5% 1/10W
R727 1-216-809-11 METAL CHIP 100 5% 1/10W
R728 1-216-809-11 METAL CHIP 100 5% 1/10W
R731 1-216-809-11 METAL CHIP 100 5% 1/10W
R732 1-216-809-11 METAL CHIP 100 5% 1/10W
R733 1-216-809-11 METAL CHIP 100 5% 1/10W
R734 1-216-809-11 METAL CHIP 100 5% 1/10W
R741 1-216-833-11 METAL CHIP 10K 5% 1/10W
R746 1-216-833-11 METAL CHIP 10K 5% 1/10W
R747 1-216-809-11 METAL CHIP 100 5% 1/10W
R748 1-216-809-11 METAL CHIP 100 5% 1/10W
R751 1-216-809-11 METAL CHIP 100 5% 1/10W
R752 1-216-809-11 METAL CHIP 100 5% 1/10W
R753 1-216-809-11 METAL CHIP 100 5% 1/10W
R757 1-216-809-11 METAL CHIP 100 5% 1/10W
R759 1-216-809-11 METAL CHIP 100 5% 1/10W
R760 1-216-809-11 METAL CHIP 100 5% 1/10W
R766 1-216-849-11 METAL CHIP 220K 5% 1/10W
R768 1-216-809-11 METAL CHIP 100 5% 1/10W
R769 1-216-809-11 METAL CHIP 100 5% 1/10W
R770 1-216-809-11 METAL CHIP 100 5% 1/10W
R773 1-216-809-11 METAL CHIP 100 5% 1/10W
R774 1-216-857-11 METAL CHIP 1M 5% 1/10W
R777 1-216-809-11 METAL CHIP 100 5% 1/10W
R778 1-216-809-11 METAL CHIP 100 5% 1/10W
R780 1-216-809-11 METAL CHIP 100 5% 1/10W
R781 1-216-809-11 METAL CHIP 100 5% 1/10W
R782 1-216-809-11 METAL CHIP 100 5% 1/10W
R783 1-216-809-11 METAL CHIP 100 5% 1/10W
R784 1-216-809-11 METAL CHIP 100 5% 1/10W
R785 1-216-809-11 METAL CHIP 100 5% 1/10W
R786 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R789 1-216-821-11 METAL CHIP 1K 5% 1/10W
R791 1-216-809-11 METAL CHIP 100 5% 1/10W
R792 1-216-809-11 METAL CHIP 100 5% 1/10W
R793 1-216-809-11 METAL CHIP 100 5% 1/10W
< VIBRATOR >
X301 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X302 1-814-062-21 VIBRATOR, CERAMIC (5MHz)
************************************************************
MOTOR BOARD
************
< CONNECTOR >
CN001 1-779-542-21 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< SWITCH >
S001 1-786-509-11 SWITCH, ROTARY
(DISC TRAY OPEN/CLOSE DETECT)
************************************************************
PANEL BOARD
***********
< CAPACITOR >
C804 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C805 1-126-947-11 ELECT 47uF 20% 35V
C811 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C812 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C814 1-126-965-91 ELECT 22uF 20% 50V
C815 1-126-965-91 ELECT 22uF 20% 50V
C816 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C841 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C907 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C908 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C909 1-126-967-11 ELECT 47uF 20% 50V
C910 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C917 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C918 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C919 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C920 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C924 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< DIODE >
D807 6-501-169-01 DIODE UDZW-TE17-6.2B
D902 6-500-641-01 LED SLI-325URC (STANDBY)
D904 6-500-334-01 DIODE MC2836-T112-1
D905 6-500-335-01 DIODE MC2838-T112-1
D915 6-500-335-01 DIODE MC2838-T112-1
< FERRITE BEAD >
FB901 1-414-235-22 INDUCTOR, FERRITE BEAD
< FLUORESCENT INDICATOR TUBE >
FL901 1-519-993-21 INDICATOR TUBE, FLUORESCENT
< IC >
IC901 6-600-349-31 IC NJL24H400A
IC902 6-711-008-01 IC PT6302LQ-010
< COIL >
L901 1-410-645-31 INDUCTOR 100uH
< TRANSISTOR >
Q901 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q903 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q905 8-729-120-28 TRANSISTOR 2SC1623-L5L6
MAIN MOTOR PANEL
