Sony HCD-BX77DBi - ELECTRICAL PARTS LIST - PANEL, POWER, TOP KEY; Panel, Power, and Top Key Board Parts

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-BX77DBi
58
< RESISTOR >
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R919 1-216-864-11 SHORT CHIP 0
R920 1-216-864-11 SHORT CHIP 0
R921 1-216-805-11 METAL CHIP 47 5% 1/10W
R922 1-216-805-11 METAL CHIP 47 5% 1/10W
R925 1-216-817-11 METAL CHIP 470 5% 1/10W
R929 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R930 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R931 1-216-833-11 METAL CHIP 10K 5% 1/10W
R932 1-216-809-11 METAL CHIP 100 5% 1/10W
R933 1-216-809-11 METAL CHIP 100 5% 1/10W
R934 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-864-11 SHORT CHIP 0
R937 1-216-864-11 SHORT CHIP 0
R938 1-216-864-11 SHORT CHIP 0
R942 1-216-833-11 METAL CHIP 10K 5% 1/10W
R943 1-216-837-11 METAL CHIP 22K 5% 1/10W
R944 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (l/
1
)
S803 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE
A
)
< TRANSFORMER >
T801 1-445-365-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
POWER BOARD
************
< CAPACITOR >
C901 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C902 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C905 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C906 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C914 1-126-964-11 ELECT 10uF 20% 50V
0 C921 1-126-767-51 ELECT 1000uF 20% 16V
0 C922 1-126-953-61 ELECT 2200uF 20% 35V
0 C923 1-126-953-61 ELECT 2200uF 20% 35V
0 C925 1-126-768-11 ELECT 2200uF 20% 16V
0 C936 1-126-943-51 ELECT 2200uF 20% 25V
< CONNECTOR >
0 CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
CN904 1-819-140-11 PIN, CONNECTOR 12P
< DIODE >
D906 6-501-817-01 DIODE MA2J1110GLS0
D907 6-500-334-01 DIODE MC2836-T112-1
D908 6-500-335-01 DIODE MC2838-T112-1
D911 6-501-582-01 DIODE 1N4002-B5
D912 6-501-582-01 DIODE 1N4002-B5
D913 6-501-582-01 DIODE 1N4002-B5
D914 6-501-582-01 DIODE 1N4002-B5
D916 6-501-569-01 DIODE 1N5401-C352
D917 6-501-569-01 DIODE 1N5401-C352
D918 6-501-569-01 DIODE 1N5401-C352
D919 6-501-569-01 DIODE 1N5401-C352
D920 6-500-335-01 DIODE MC2838-T112-1
D922 6-501-817-01 DIODE MA2J1110GLS0
D923 6-500-335-01 DIODE MC2838-T112-1
D924 6-501-582-01 DIODE 1N4002-B5
D925 6-501-582-01 DIODE 1N4002-B5
D926 6-501-582-01 DIODE 1N4002-B5
D927 6-501-582-01 DIODE 1N4002-B5
< FUSE HOLDER >
FH901 1-533-233-31 FUSE HOLDER
FH902 1-533-233-31 FUSE HOLDER
FH903 1-533-233-31 FUSE HOLDER
FH904 1-533-233-31 FUSE HOLDER
< LINE FILTER >
0 LF901 1-443-993-11 TRANSFORMER, LINE FILTER (LFT)
< RESISTOR >
R901 1-216-837-11 METAL CHIP 22K 5% 1/10W
R902 1-216-837-11 METAL CHIP 22K 5% 1/10W
R904 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R906 1-216-833-11 METAL CHIP 10K 5% 1/10W
R908 1-216-821-11 METAL CHIP 1K 5% 1/10W
R909 1-216-821-11 METAL CHIP 1K 5% 1/10W
R910 1-216-864-11 SHORT CHIP 0
R911 1-216-864-11 SHORT CHIP 0
< RELAY >
0 RY901 1-755-334-11 RELAY, AC POWER
< TRANSFORMER >
0 T902 1-443-912-11 TRANSFORMER, POWER
************************************************************
TOP KEY BOARD
*************
< RESISTOR >
R853 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R854 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R855 1-216-833-11 METAL CHIP 10K 5% 1/10W
R856 1-216-835-11 METAL CHIP 15K 5% 1/10W
R857 1-216-835-11 METAL CHIP 15K 5% 1/10W
R860 1-216-821-11 METAL CHIP 1K 5% 1/10W
R861 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R862 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R863 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R864 1-216-821-11 METAL CHIP 1K 5% 1/10W
R865 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R866 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R867 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R868 1-216-833-11 METAL CHIP 10K 5% 1/10W
R869 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S804 1-762-875-21 SWITCH, KEYBOARD (AUDIO IN)
S805 1-762-875-21 SWITCH, KEYBOARD (CD
u
)
S806 1-762-875-21 SWITCH, KEYBOARD (iPod
u
)
PANEL POWER TOP KEY
