Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 120 —
* 1-672-190-12 FRONT INPUT BOARD
*****************
< CAPACITOR >
C801 1-162-294-31 CERAMIC 0.001uF 10% 50V
C802 1-162-294-31 CERAMIC 0.001uF 10% 50V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C812 1-164-159-21 CERAMIC 0.1uF 50V
C813 1-126-960-11 ELECT 1uF 20% 50V
< FILTER >
FL803 1-424-228-11 FILTER, NOISE
< JACK >
J804 1-764-592-41 JACK 3P (VIDEO2)
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-417-11 CARBON 1K 5% 1/4W F
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
* A-4417-530-A JACK BOARD, COMPLETE
*********************
< CAPACITOR >
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-961-11 ELECT 2.2uF 20% 50V
C807 1-162-294-31 CERAMIC 0.001uF 10% 50V
C808 1-162-294-31 CERAMIC 0.001uF 10% 50V
C809 1-164-159-21 CERAMIC 0.1uF 50V
C810 1-164-159-21 CERAMIC 0.1uF 50V
C856 1-162-294-31 CERAMIC 0.001uF 10% 50V
C857 1-162-215-31 CERAMIC 47PF 5% 50V
C858 1-126-964-11 ELECT 10uF 20% 50V
C859 1-126-961-11 ELECT 2.2uF 20% 50V
C860 1-162-215-31 CERAMIC 47PF 5% 50V
C861 1-162-282-31 CERAMIC 100PF 10% 50V
C862 1-126-961-11 ELECT 2.2uF 20% 50V
C863 1-126-960-11 ELECT 1uF 20% 50V
C864 1-126-964-11 ELECT 10uF 20% 50V
C882 1-162-290-31 CERAMIC 470PF 10% 50V
C883 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN802 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< EARTH >
* EPT802 1-537-738-21 TERMINAL, EARTH
< FILTER >
FL801 1-424-228-11 FILTER, NOISE
FL802 1-424-228-11 FILTER, NOISE
< IC >
IC850 8-759-634-50 IC M5218AL
< JACK >
J801 1-770-226-11 JACK (LARGE TYPE) (MIX MIC)
J803 1-770-226-11 JACK (LARGE TYPE) (PHONES)
< RESISTOR >
R807 1-249-429-11 CARBON 10K 5% 1/4W
R809 1-249-417-11 CARBON 1K 5% 1/4W F
R810 1-247-807-31 CARBON 100 5% 1/4W
R850 1-247-807-31 CARBON 100 5% 1/4W
R852 1-249-441-11 CARBON 100K 5% 1/4W
R853 1-249-417-11 CARBON 1K 5% 1/4W F
R854 1-247-863-91 CARBON 22K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-885-00 CARBON 180K 5% 1/4W
R857 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV850 1-225-587-11 RES, VAR, CARBON 50K (MIC VOL)
************************************************************
* 1-659-059-13 LED (CD) BOARD
**************
< LED >
D201 8-719-032-98 LED SEL5820A (DISK NO.)
< TRANSISTOR >
Q201 8-729-119-78 TRANSISTOR 2SC403SP-51
< RESISTOR >
R201 1-247-863-91 CARBON 22K 5% 1/4W
R202 1-249-411-11 CARBON 330 5% 1/4W
R203 1-249-437-11 CARBON 47K 5% 1/4W
************************************************************
* 1-672-195-11 LED (PANEL) BOARD
*****************
< LED >
D671 8-719-058-03 LED SEL5423E-TP15 (DISK TABLE)
D672 8-719-058-03 LED SEL5423E-TP15 (DISK TABLE)
D673 8-719-058-03 LED SEL5423E-TP15 (DISK TABLE)
D674 8-719-058-03 LED SEL5423E-TP15 (DISK TABLE)
< RESISTOR >
R600 1-249-410-11 CARBON 270 5% 1/4W F
************************************************************
A-2007-800-A LEAF SW BOARD, COMPLETE
*************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
FRONT INPUT JACK LED (CD) LED (PANEL) LEAF SW
