Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 121 —
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77
D1002 8-719-991-33 DIODE 1SS133T-77
< CABLE HOLDER >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-249-441-11 CARBON 100K 5% 1/4W
R1001 1-247-815-91 CARBON 220 5% 1/4W
R1002 1-247-815-91 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-91 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-205-11 SWITCH, LEAF (B120/70)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
************************************************************
* A-4417-544-A MAIN BOARD, COMPLETE (DR8AV:E,MX,AR)
*********************
* A-4419-303-A MAIN BOARD, COMPLETE (DR8AV:EA)
*********************
* A-4419-302-A MAIN BOARD, COMPLETE (DR8AV:SP,AUS)
*********************
* A-4417-543-A MAIN BOARD, COMPLETE (W900AV)
*********************
4-875-327-31 HEATSINK
7-685-646-79 SCREW+BVTP 3 × 8 TYPE2 N-S
< CAPACITOR >
C111 1-137-195-11 FILM 0.56uF 5% 50V
C112 1-136-158-00 FILM 0.027uF 5% 50V
C113 1-136-167-00 FILM 0.15uF 5% 50V
C114 1-130-480-00 MYLAR 0.0056uF 5% 50V
C115 1-136-159-00 FILM 0.033uF 5% 50V
C116 1-130-473-00 MYLAR 0.0015uF 5% 50V
C117 1-136-153-00 FILM 0.01uF 5% 50V
C118 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C119 1-130-479-00 MYLAR 0.0047uF 5% 50V
C120 1-130-477-00 MYLAR 0.0033uF 5% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C123 1-136-169-00 FILM 0.22uF 5% 50V
C124 1-136-169-00 FILM 0.22uF 5% 50V
C125 1-126-964-11 ELECT 10uF 20% 50V
C131 1-104-664-11 ELECT 47uF 20% 16V
C132 1-104-664-11 ELECT 47uF 20% 16V
C135 1-126-964-11 ELECT 10uF 20% 50V
C161 1-137-195-11 FILM 0.56uF 5% 50V
C162 1-136-158-00 FILM 0.027uF 5% 50V
C163 1-136-167-00 FILM 0.15uF 5% 50V
C164 1-130-480-00 MYLAR 0.0056uF 5% 50V
C165 1-136-159-00 FILM 0.033uF 5% 50V
C166 1-130-473-00 MYLAR 0.0015uF 5% 50V
C167 1-136-153-00 FILM 0.01uF 5% 50V
C168 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C169 1-130-479-00 MYLAR 0.0047uF 5% 50V
C170 1-130-477-00 MYLAR 0.0033uF 5% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C173 1-136-169-00 FILM 0.22uF 5% 50V
C174 1-136-169-00 FILM 0.22uF 5% 50V
C175 1-126-964-11 ELECT 10uF 20% 50V
C176 1-136-495-11 FILM 0.068uF 5% 50V
C177 1-136-153-00 FILM 0.01uF 5% 50V
C181 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C182 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C183 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C191 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C193 1-126-964-11 ELECT 10uF 20% 50V
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-959-11 ELECT 0.47uF 20% 50V
C204 1-126-959-11 ELECT 0.47uF 20% 50V
C207 1-126-959-11 ELECT 0.47uF 20% 50V
C208 1-126-959-11 ELECT 0.47uF 20% 50V
C209 1-126-959-11 ELECT 0.47uF 20% 50V
C210 1-126-959-11 ELECT 0.47uF 20% 50V
C211 1-126-959-11 ELECT 0.47uF 20% 50V
C212 1-126-959-11 ELECT 0.47uF 20% 50V
C213 1-136-165-00 FILM 0.1uF 5% 50V
C214 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C215 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C216 1-126-960-11 ELECT 1uF 20% 50V
C217 1-130-479-00 MYLAR 0.0047uF 5% 50V
C218 1-130-471-00 MYLAR 0.001uF 5% 50V
C219 1-136-169-00 FILM 0.22uF 5% 50V
C220 1-136-169-00 FILM 0.22uF 5% 50V
C221 1-136-169-00 FILM 0.22uF 5% 50V
C222 1-136-169-00 FILM 0.22uF 5% 50V
C223 1-130-479-00 MYLAR 0.0047uF 5% 50V
C224 1-130-471-00 MYLAR 0.001uF 5% 50V
C225 1-126-960-11 ELECT 1uF 20% 50V
C226 1-130-480-00 MYLAR 0.0056uF 5% 50V
C227 1-136-161-00 FILM 0.047uF 5% 50V
LEAF SW MAIN
