10
HCD-EC55/EC77/GX99
3-3. TOP PANEL ASSY (EXCEPT US, CND)
3-4. TOP PANEL (US, CND)
5
two
claws
4
two screws
(+BVTP3
×
10
)
7
Remove the top panel
in the direction of the arrow.
1
screw
(+KTP3
×
10
)
2
screw
(+KTP3
×
10
)
3
two screws
(+BVTP3
×
10
)
6
dowel
6
two
claws
4
two screws
(+BVTP3
×
10
)
8
Remove the top panel assy
in the direction of the arrow.
1
screw
(+KTP3
×
10
)
2
screw
(+KTP3
×
10
)
3
two screws
(+BVTP3
×
10
)
7
dowel
5
wire (flat type)
9core (CN606)
