20
HCD-EC55/EC77/GX99
3-18. HI-AMP BOARD (EC55)
3
HI-AMP board
1
screw
(+BV3
×
10
)
2
two transisitor
screws
3-19. DC FAN
2
DC fan
1
four screws
(+BVTP3
×
10
)
