15
HCD-EC55/EC77/GX99
3-11. MAIN BOARD
9
two screws
(+BVTP3
×
10
)
0
two screws
(+BVTP3
×
10
)
5
connector
(CN604)
7
two screws
(+BVTP3
×
6
)
6
two screws
(+BVTP3
×
10
)
qd
MAIN board
4
connector
(CN601)
3
wire (flat type)
21core (CN608)
8
screw
(+BVTP3
×
10
)
qa
Remove the soldering.
qs
REG board
2
wire (flat type)
27core (CN607)
1
wire (flat type)
9core (CN605)
(EC77/GX99)
