24
HCD-EC55/EC77/GX99
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN301 1-779-564-21 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
CN302 1-784-735-11 CONNECTOR, FFC 13P
< DIODE >
D301 6-501-722-01 DIODE MAZ8043GMLS0
D302 8-719-404-50 DIODE MA111-TX
D303 8-719-000-07 DIODE MC2836
D304 8-719-404-50 DIODE MA111-TX
D305 8-719-404-50 DIODE MA111-TX
< IC >
IC301 6-807-577-01 IC MB90803PF-G-130E1
IC302 6-600-349-31 IC NJL24H400A
< JUMPER RESISTOR >
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-296-11 SHORT CHIP 0
JR303 1-216-296-11 SHORT CHIP 0
JR304 1-216-296-11 SHORT CHIP 0
JR305 1-216-296-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-296-11 SHORT CHIP 0
JR308 1-216-296-11 SHORT CHIP 0
JR309 1-216-296-11 SHORT CHIP 0
JR310 1-216-864-11 SHORT CHIP 0
JR311 1-216-864-11 SHORT CHIP 0
JR312 1-216-296-11 SHORT CHIP 0
JR313 1-216-864-11 SHORT CHIP 0
JR314 1-216-296-11 SHORT CHIP 0
JR315 1-216-296-11 SHORT CHIP 0
JR316 1-216-296-11 SHORT CHIP 0
JR317 1-216-296-11 SHORT CHIP 0
JR318 1-216-296-11 SHORT CHIP 0
JR319 1-216-864-11 SHORT CHIP 0
JR320 1-216-296-11 SHORT CHIP 0
JR321 1-216-296-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD301 1-805-973-11 DISPLAY PANEL, LIQUID CRYSTAL
< LED >
LED301 6-501-479-01 DIODE 1L0341Y23E0CA602 (BACK LIGHT)
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-037-13 TRANSISTOR KTA1271Y
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q307 8-729-600-22 TRANSISTOR 2SA1235-F
Q308 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q309 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q310 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q311 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q312 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q313 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q314 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q315 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q316 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q317 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q318 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
< RESISTOR >
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
R305 1-216-809-11 METAL CHIP 100 5% 1/10W
R306 1-216-809-11 METAL CHIP 100 5% 1/10W
R307 1-216-809-11 METAL CHIP 100 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-809-11 METAL CHIP 100 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R311 1-216-809-11 METAL CHIP 100 5% 1/10W
R312 1-216-809-11 METAL CHIP 100 5% 1/10W
R313 1-216-809-11 METAL CHIP 100 5% 1/10W
R314 1-216-809-11 METAL CHIP 100 5% 1/10W
R315 1-216-809-11 METAL CHIP 100 5% 1/10W
R316 1-216-809-11 METAL CHIP 100 5% 1/10W
R317 1-216-809-11 METAL CHIP 100 5% 1/10W
R318 1-216-809-11 METAL CHIP 100 5% 1/10W
R319 1-216-809-11 METAL CHIP 100 5% 1/10W
R320 1-216-809-11 METAL CHIP 100 5% 1/10W
R321 1-216-809-11 METAL CHIP 100 5% 1/10W
R322 1-216-809-11 METAL CHIP 100 5% 1/10W
R323 1-216-809-11 METAL CHIP 100 5% 1/10W
R324 1-216-809-11 METAL CHIP 100 5% 1/10W
R325 1-216-797-11 METAL CHIP 10 5% 1/10W
R326 1-216-809-11 METAL CHIP 100 5% 1/10W
R327 1-216-809-11 METAL CHIP 100 5% 1/10W
R328 1-216-833-11 METAL CHIP 10K 5% 1/10W
R329 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R330 1-216-819-11 METAL CHIP 680 5% 1/10W
R331 1-216-845-11 METAL CHIP 100K 5% 1/10W
R332 1-216-833-11 METAL CHIP 10K 5% 1/10W
R333 1-216-845-11 METAL CHIP 100K 5% 1/10W
R334 1-216-833-11 METAL CHIP 10K 5% 1/10W
R335 1-216-833-11 METAL CHIP 10K 5% 1/10W
R336 1-216-833-11 METAL CHIP 10K 5% 1/10W
R337 1-216-864-11 SHORT CHIP 0
R338 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R339 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R340 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R341 1-216-839-11 METAL CHIP 33K 5% 1/10W
R342 1-216-849-11 METAL CHIP 220K 5% 1/10W
R343 1-216-853-11 METAL CHIP 470K 5% 1/10W
R344 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R345 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R346 1-216-841-11 METAL CHIP 47K 5% 1/10W
R347 1-216-817-11 METAL CHIP 470 5% 1/10W
PANEL
Ver. 1.2
