HCD-EC69i/EC79i/EC99i
12
3-6. MAIN BOARD
(HCD-EC69i/EC79i: US, Canadian)
3-5. BASE (DOCK)
Note: This illustration sees the front panel from bottom side.
two screws
(B2.6)
base (dock)
Left up the IP board.
boss
boss
connector
(CN504)
MAIN board
flexible flat cable (5 core)
(CN603)
fan motor connector
(CN601)
connector
(EC69i: CN102, EC79i: CN101)
two screws
(BVTP3
×
10)
two screws
(BVTP3
×
10)
connector
(CN609)
