HCD-EC69i/EC79i/EC99i
7-2. OVERALL SECTION
(HCD-EC79i/EC99i)
51 2-890-831-01 PANEL (L), SIDE (US, CND)
51 2-890-831-11 PANEL (L), SIDE (UK, AUS)
52 3-363-099-32 SCREW (CASE 3 TP2)
53 2-890-830-01 PANEL (R), SIDE (US, CND)
53 2-890-830-11 PANEL (R), SIDE (UK, AUS)
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-247-14 SCREW +KTP 3X10 TYPE2 NON-SLIT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
#1
#2
#2
#1
#1
#1
#1
51
52
53
52
MAIN boad section
(HCD-EC79i/EC99i)
front panel section
not supplied
A
C
E
D
B
(EC79i:
US, CND)
#1
#1
top panel section
(HCD-EC79i: UK, AUS/EC99i)
top panel section
(HCD-EC69i/EC79i: US, CND)
A
B
C
E
C
D
D
A
(EC79i: US, CND)
