HCD-EC69i/EC79i/EC99i
SECTION 8
ELECTRICAL PARTS LIST
2CH-4CH AMP BOARD
*****************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C108 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C109 1-126-947-11 ELECT 47uF 20% 35V
C110 1-126-947-11 ELECT 47uF 20% 35V
C111 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C112 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC79i)
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC79i)
C121 1-126-960-11 ELECT 1uF 20% 50V
(EC79i)
C122 1-126-960-11 ELECT 1uF 20% 50V
(EC79i)
C123 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(EC79i)
C124 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(EC79i)
C125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(EC79i)
C126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(EC79i)
C127 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(EC79i)
C128 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(EC79i)
C129 1-126-960-11 ELECT 1uF 20% 50V
(EC79i)
C130 1-126-960-11 ELECT 1uF 20% 50V
(EC79i)
C141 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C142 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C151 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79i)
C152 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79i)
C160 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C161 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C162 1-126-968-11 ELECT 100uF 20% 50V
(EC69i)
C162 1-128-553-11 ELECT 220uF 20% 63V
(EC79i)
C162 1-128-576-11 ELECT 100uF 20% 63V
(EC99i)
C163 1-126-968-11 ELECT 100uF 20% 50V
(EC69i)
C163 1-128-553-11 ELECT 220uF 20% 63V
(EC79i)
C163 1-128-576-11 ELECT 100uF 20% 63V
(EC99i)
C164 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C165 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C166 1-128-582-11 ELECT 10uF 20% 100V
(EC79i)
C167 1-128-582-11 ELECT 10uF 20% 100V
(EC79i)
< CONNECTOR >
CN100 1-784-766-11 CONNECTOR, FFC 5P
CN101 1-820-831-11 HOLDER, CABLE 7P (EC79i)
CN102 1-824-030-21 HOLDER, CABLE 5P (EC69i/EC99i)
< DIODE >
D140 6-501-817-01 DIODE MA2J1110GLS0
D141 6-500-335-01 DIODE MC2838-T112-1
D152 6-500-335-01 DIODE MC2838-T112-1 (EC79i)
< IC >
IC101 6-600-732-01 IC STK433-890-E (EC79i)
IC102 6-705-625-01 IC STK433-040 (EC69i)
IC103 6-600-580-01 IC STK433-090-E (EC99i)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q141 6-551-270-01 TRANSISTOR 2SA2026
Q142 6-551-270-01 TRANSISTOR 2SA2026
Q151 6-551-270-01 TRANSISTOR 2SA2026 (EC79i)
Q152 6-551-270-01 TRANSISTOR 2SA2026 (EC79i)
