HCD-EC69i/EC79i/EC99i
17
3-16. OPTICAL PICK-UP BLOCK (KSM-213DCP)
(HCD-EC79i: UK, Australian/EC99i)
3-15. BASE UNIT (BU-K6BD90-WOD)
(HCD-EC79i: UK, Australian/EC99i)
Note: This illustration sees the base unit from CD board side.
four screws
(PTPWH M2.6)
two coil springs (insulator)
two coil springs (insulator)
two insulators
two insulators
base unit
(BU-K6BD90-WOD)
top panel block
(bottom view)
flexible flat cable (16 core)
(optical pick-up, CD board: CN201)
optical pick-up block
(KSM-213DCP)
CD board
Remove the four solders.
