HCD-EC69i/EC79i/EC99i
13
3-7. FRONT PANEL BLOCK
(HCD-EC69i/EC79i: US, Canadian)
3-8. BASE UNIT BLOCK (BU-K8BD90-WOD)
(HCD-EC69i/EC79i: US, Canadian)
Note: This illustration sees the base unit from CD board side.
4
three screws
(BVTP3
u
10)
1
flexible flat cable (25 core)
(CN607)
2
flexible flat cable (11 core)
(CN653)
3
flexible flat cable (7 core)
(EC69i: CN606),
flexible flat cable (9 core)
(EC79i (US, Canadian): CN605)
5
front panel block
top panel block
(bottom view)
four screws
(PWH B2.6)
two vibration proof rubbers
(red)
two vibration proof rubbers
(green)
four claws
CD cover
base unit
(BU-K8BD90-WOD)
