HCD-EC69i/EC79i/EC99i
16
3-14. FRONT PANEL BLOCK
(HCD-EC79i: UK, Australian/EC99i)
3-13. MAIN BOARD
(HCD-EC79i: UK, Australian/EC99i)
three screws
(BVTP3
×
10)
flexible flat cable (25 core)
(CN607)
flexible flat cable (11 core)
(CN653)
flexible flat cable (9 core)
(CN605)
front panel block
fan motor connector
(CN601)
connector
(CN609)
connector
(EC99i: CN102)
connector
(EC79i: CN101,
EC99i: CN205)
connector
(EC79i: CN704,
EC99i: CN654)
flexible flat cable (5 core)
(CN603)
flexible flat cable (7 core)
(EC99i: CN643)
two screws
(BVTP3
×
10)
RT
MAIN board
two screws
(BVTP3
×
10)
four screws
(BVTP3
×
10)
(EC99i)
R
screw
(BVTP3
×
10)
RB
bracket (PWB)
