Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69i/EC79i/EC99i
5959
R905 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R906 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R907 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R908 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R909 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R910 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R911 1-218-907-11 METAL CHIP 330K 0.5% 1/10W
R912 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R913 1-216-809-11 METAL CHIP 100 5% 1/10W
R914 1-216-809-11 METAL CHIP 100 5% 1/10W
R917 1-216-811-11 METAL CHIP 150 5% 1/10W
(EC79i/EC99i)
R920 1-216-811-11 METAL CHIP 150 5% 1/10W
(EC79i/EC99i)
************************************************************
JACK BOARD
**********
< CAPACITOR >
C495 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C496 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN496 1-784-770-11 CONNECTOR, FFC 9P (EC79i/EC99i)
CN497 1-568-826-11 CONNECTOR, FFC 7P (EC69i)
< DIODE >
D491 8-719-062-51 DIODE 1PS226-115 (EC79i/EC99i)
< JACK >
J491 1-566-822-51 JACK (PC IN) (EC79i/EC99i)
J492 1-815-629-21 JACK (PHONES)
< RESISTOR >
R491 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EC79i/EC99i)
R492 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EC79i/EC99i)
************************************************************
KEY BOARD
*********
< CONNECTOR >
CN313 1-815-551-11 PIN, CONNECTOR (PWB) 3P
< RESISTOR >
R404 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R405 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R406 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R407 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R408 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(EC79i: UK, AUS/EC99i)
< SWITCH >
SW311 1-771-410-21 SWITCH, TACTILE (
x
)
SW321 1-771-410-21 SWITCH, TACTILE (CD)
SW322 1-771-410-21 SWITCH, TACTILE (iPod)
SW323 1-771-410-21 SWITCH, TACTILE (FOLDER +)
SW324 1-771-410-21 SWITCH, TACTILE (TUNING +,
M
L
)
SW325 1-771-410-21 SWITCH, TACTILE (DSGX)
SW326 1-771-410-21 SWITCH, TACTILE (
Z
) (EC79i: UK, AUS/EC99i)
************************************************************
LOADING BOARD (EC79i: UK, AUS/EC99i)
**************
When the LOADING board is damaged, exchange the entire CDM76A Assy (EC79i:
UK, Australian/EC99i).
************************************************************
A-1599-061-A MAIN BOARD, COMPLETE (EC99i: US, CND)
A-1599-076-A MAIN BOARD, COMPLETE (EC99i: UK, AUS)
A-1599-082-A MAIN BOARD, COMPLETE (EC79i: US, CND)
A-1599-088-A MAIN BOARD, COMPLETE (EC79i: UK, AUS)
A-1599-114-A MAIN BOARD, COMPLETE (EC69i: US, CND)
A-1599-131-A MAIN BOARD, COMPLETE (EC69i: UK, AUS)
********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S (EC99i)
< CAPACITOR >
C601 1-126-962-11 ELECT 3.3uF 20% 50V
C602 1-126-947-11 ELECT 47uF 20% 35V
C603 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC79i/EC99i)
C604 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79i/EC99i)
C605 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79i/EC99i)
C606 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC79i/EC99i)
C607 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C608 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C609 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C610 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C611 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C612 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C613 1-126-964-11 ELECT 10uF 20% 50V
C614 1-126-963-11 ELECT 4.7uF 20% 50V
C615 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79i/EC99i)
C616 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79i/EC99i)
C617 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C618 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C619 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C620 1-104-658-91 ELECT 100uF 20% 10V
C621 1-130-777-00 MYLAR 0.1uF 5% 100V
C622 1-114-471-51 ELECT 3300uF 20% 63V
(EC79i/EC99i)
C622 1-128-550-11 ELECT 2200uF 20% 50V
(EC69i)
C623 1-130-777-00 MYLAR 0.1uF 5% 100V
C624 1-126-923-91 ELECT 220uF 20% 10V
(EC79i/EC99i)
C626 1-114-471-51 ELECT 3300uF 20% 63V
(EC79i/EC99i)
C626 1-128-550-11 ELECT 2200uF 20% 50V
(EC69i)
C627 1-126-943-11 ELECT 2200uF 20% 25V
C628 1-126-942-61 ELECT 1000uF 20% 25V
C629 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
IP JACK KEY LOADING MAIN
