38
HCD-EP313
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D306 8-719-991-33 DIODE 1SS133T-72
D307 8-719-991-33 DIODE 1SS133T-72
D308 8-719-991-33 DIODE 1SS133T-72
< FERRITE BEAD >
FB301 1-400-297-11 INDUCTOR 0uH
FB303
< IC >
IC301 6-802-783-01 IC LC877140A-51E2
IC302 6-700-250-01 IC PST3445UL
IC303 6-701-681-01 IC RPM7140-V4
< JUMPER RESISTOR >
JR301 1-216-864-11 METAL CHIP 0 5% 1/16W
JR302 1-216-864-11 METAL CHIP 0 5% 1/16W
JR303 1-216-864-11 METAL CHIP 0 5% 1/16W
JR304 1-216-864-11 METAL CHIP 0 5% 1/16W
JR305 1-216-864-11 METAL CHIP 0 5% 1/16W
JR306 1-216-295-91 SHORT CHIP 0
JR307 1-216-295-91 SHORT CHIP 0
JR308 1-216-295-91 SHORT CHIP 0
JR309 1-216-295-91 SHORT CHIP 0
JR310 1-216-295-91 SHORT CHIP 0
JR311 1-216-295-91 SHORT CHIP 0
JR312 1-216-295-91 SHORT CHIP 0
JR313 1-216-295-91 SHORT CHIP 0
JR314 1-216-295-91 SHORT CHIP 0
JR315 1-216-295-91 SHORT CHIP 0
JR317 1-216-864-11 METAL CHIP 0 5% 1/16W
JR318 1-216-864-11 METAL CHIP 0 5% 1/16W
JR319 1-216-295-91 SHORT CHIP 0
JR320 1-216-295-91 SHORT CHIP 0
< COIL >
L301
L302 1-408-117-00 INDUCTOR 10uH
L304
< LIQUID CRYSTAL DISPLAY >
LCD301 1-805-184-11 DISPLAY PANEL, LIQUID CRYSTAL
< LED >
LED301 8-719-059-98 DIODE SLR-342VCT31 (STANDBY)
< TRANSISTOR >
Q301 8-729-230-49 TRANSISTOR 2SC2712L-TE85R
Q302 8-729-230-49 TRANSISTOR 2SC2712L-TE85R
Q303 6-550-296-01 TRANSISTOR 2SA1980G
Q304 8-729-230-49 TRANSISTOR 2SC2712L-TE85R
Q305 8-729-230-49 TRANSISTOR 2SC2712L-TE85R
Q306 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R300 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R301 1-216-821-11 METAL CHIP 1K 5% 1/16W
R302 1-216-821-11 METAL CHIP 1K 5% 1/16W
R303 1-216-821-11 METAL CHIP 1K 5% 1/16W
R304 1-216-821-11 METAL CHIP 1K 5% 1/16W
R305 1-216-821-11 METAL CHIP 1K 5% 1/16W
R306 1-216-821-11 METAL CHIP 1K 5% 1/16W
R307 1-216-809-11 METAL CHIP 100 5% 1/16W
R308 1-216-821-11 METAL CHIP 1K 5% 1/16W
R309 1-216-821-11 METAL CHIP 1K 5% 1/16W
R310 1-216-814-11 METAL CHIP 270 5% 1/16W
R311 1-216-814-11 METAL CHIP 270 5% 1/16W
R312 1-216-809-11 METAL CHIP 100 5% 1/16W
R313 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R314 1-216-821-11 METAL CHIP 1K 5% 1/16W
R315 1-216-821-11 METAL CHIP 1K 5% 1/16W
R316 1-216-809-11 METAL CHIP 100 5% 1/16W
R317 1-216-821-11 METAL CHIP 1K 5% 1/16W
R318 1-216-810-11 RES CHIP 120 5% 1/10W
R319 1-216-809-11 METAL CHIP 100 5% 1/16W
R320 1-216-809-11 METAL CHIP 100 5% 1/16W
R321 1-216-809-11 METAL CHIP 100 5% 1/16W
R322 1-249-417-11 CARBON 1K 5% 1/4W F
R323 1-216-821-11 METAL CHIP 1K 5% 1/16W
R324 1-216-821-11 METAL CHIP 1K 5% 1/16W
R325 1-216-809-11 METAL CHIP 100 5% 1/16W
R326 1-216-809-11 METAL CHIP 100 5% 1/16W
R327 1-216-821-11 METAL CHIP 1K 5% 1/16W
R328 1-249-425-11 CARBON 4.7K 5% 1/4W F
R329 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R330 1-249-427-11 CARBON 6.8K 5% 1/4W F
R331 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R332 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R333 1-249-422-11 CARBON 2.7K 5% 1/4W F
R334 1-249-422-11 CARBON 2.7K 5% 1/4W F
R335 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R336 1-249-420-11 CARBON 1.8K 5% 1/4W F
R337 1-249-429-11 CARBON 10K 5% 1/4W
R338 1-216-833-11 METAL CHIP 10K 5% 1/16W
R339 1-216-834-11 METAL CHIP 12K 5% 1/16W
R340 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R341 1-249-425-11 CARBON 4.7K 5% 1/4W F
R342 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R344 1-249-438-11 CARBON 56K 5% 1/4W
R345 1-216-809-11 METAL CHIP 100 5% 1/16W
R346 1-216-837-11 METAL CHIP 22K 5% 1/16W
R347 1-216-837-11 METAL CHIP 22K 5% 1/16W
R348 1-216-821-11 METAL CHIP 1K 5% 1/16W
R349 1-216-841-11 METAL CHIP 47K 5% 1/16W
R350 1-216-837-11 METAL CHIP 22K 5% 1/16W
R351 1-216-843-11 METAL CHIP 68K 5% 1/16W
R352 1-216-840-11 METAL CHIP 39K 5% 1/16W
R353 1-249-425-11 CARBON 4.7K 5% 1/4W F
R354 1-216-834-11 METAL CHIP 12K 5% 1/16W
R355 1-216-821-11 METAL CHIP 1K 5% 1/16W
R356 1-216-821-11 METAL CHIP 1K 5% 1/16W
R357 1-216-821-11 METAL CHIP 1K 5% 1/16W
R358 1-216-817-11 METAL CHIP 470 5% 1/16W
R359 1-245-191-21 METAL CHIP 10K 1% 1/10W
R360 1-216-833-11 METAL CHIP 10K 5% 1/16W
R361 1-216-809-11 METAL CHIP 100 5% 1/16W
R362 1-216-821-11 METAL CHIP 1K 5% 1/16W
R363 1-216-833-11 METAL CHIP 10K 5% 1/16W
R364 1-216-821-11 METAL CHIP 1K 5% 1/16W
R365 1-216-845-11 METAL CHIP 100K 5% 1/16W
CONTROL
