39
HCD-EP313
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R366 1-247-887-00 CARBON 220K 5% 1/4W
R367 1-216-841-11 METAL CHIP 47K 5% 1/16W
R368 1-216-835-11 METAL CHIP 15K 5% 1/16W
R369 1-216-845-11 METAL CHIP 100K 5% 1/16W
R370 1-216-841-11 RES CHIP 47K 5% 1/10W
R371 1-249-417-11 CARBON 1K 5% 1/4W F
R372 1-216-809-11 METAL CHIP 100 5% 1/16W
R373 1-216-809-11 METAL CHIP 100 5% 1/16W
R374 1-216-809-11 METAL CHIP 100 5% 1/16W
R375 1-216-841-11 RES CHIP 47K 5% 1/10W
R376 1-216-821-11 METAL CHIP 1K 5% 1/16W
R377 1-249-429-11 CARBON 10K 5% 1/4W
R378 1-216-825-11 RES CHIP 2.2K 5% 1/10W
R379 1-216-833-11 METAL CHIP 10K 5% 1/16W
R380 1-216-810-11 RES CHIP 120 5% 1/10W
< SWITCH >
S301 1-786-050-21 SWITCH, KEY BOARD (CD)
S302 1-786-050-21 SWITCH, KEY BOARD (DISPLAY)
S303 1-786-050-21 SWITCH, KEY BOARD (MD)
S304 1-786-050-21 SWITCH, KEY BOARD (TUNER)
S305 1-786-050-21 SWITCH, KEY BOARD (>)
S306 1-786-050-21 SWITCH, KEY BOARD (DSG)
S307 1-786-050-21 SWITCH, KEY BOARD (.)
S308 1-786-050-21 SWITCH, KEY BOARD (BASS/TRE)
S309 1-786-050-21 SWITCH, KEY BOARD (x)
S310 1-786-050-21 SWITCH, KEY BOARD (M)
S311 1-786-050-21 SWITCH, KEY BOARD (l/ 1)
S312 1-786-050-21 SWITCH, KEY BOARD (m)
S313 1-786-050-21 SWITCH, KEY BOARD (X)
S314 1-786-050-21 SWITCH, KEY BOARD (PLAY/MODE)
S315 1-786-419-11 SW, RTRY RE121PVB25FINB1-24E (VOLUME)
< VIBRATOR >
X301 9-300-001-87 VIB,XTAL 32.768KHZ CFS-308 CT
X302 1-795-880-11 VIBRATOR, CERAMIC 8.64MHz
************************************************************
A-4732-950-A MAIN BOARD, COMPLETE (US,CND)
*********************
A-4732-945-A MAIN BOARD, COMPLETE (AEP,UK)
*********************
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
< CAPACITOR >
C200 1-126-941-11 ELECT 470uF 20.00% 25V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C204 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C206 1-128-548-11 ELECT 4700uF 20% 25V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C208 1-130-495-00 MYLAR 0.1uF 5% 50V
C209 1-104-666-11 ELECT 220uF 20.00% 25V
C210 1-130-495-00 MYLAR 0.1uF 5% 50V
C211 1-130-495-00 MYLAR 0.1uF 5% 50V
C212 1-130-495-00 MYLAR 0.1uF 5% 50V
C213 1-130-495-00 MYLAR 0.1uF 5% 50V
C221 1-126-960-11 ELECT 1uF 20.00% 50V
C222 1-126-947-11 ELECT 47uF 20.00% 25V
C223 1-126-962-11 ELECT 3.3uF 20.00% 50V
C224 1-126-961-11 ELECT 2.2uF 20.00% 50V
C225 1-126-961-11 ELECT 2.2uF 20.00% 50V
C226 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C227 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C228 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C229 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C240 1-126-956-91 ELECT 0.1uF 20.00% 50V
C241 1-126-956-91 ELECT 0.1uF 20.00% 50V
C242
C243
C248 1-164-156-91 CERAMIC CHIP 0.1uF 25V
C249
C400 1-126-947-11 ELECT 47uF 20.00% 25V
C415 1-216-964-11 METAL 62K 1% 0.6W
C416 1-126-935-11 ELECT 470uF 20.00% 16V
C417 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C441 1-126-934-11 ELECT 220uF 20.00% 10V
C442 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C446 1-126-947-11 ELECT 47uF 20.00% 25V
C447 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C450 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C451 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C452 1-126-934-11 ELECT 220uF 20.00% 10V
C453 1-162-979-11 CERAMIC CHIP 0.0027uF 10.00% 50V
C454 1-162-979-11 CERAMIC CHIP 0.0027uF 10.00% 50V
C455 1-162-979-11 CERAMIC CHIP 0.0027uF 10.00% 50V
C456 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C457 1-106-361-00 MYLAR 0.0056uF 5.00% 100V
C461 1-162-935-11 CERAMIC CHIP 4PF 0.25PF 50V
C462 1-162-935-11 CERAMIC CHIP 4PF 0.25PF 50V
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C502 1-126-947-11 ELECT 47uF 20.00% 25V
C540 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C588 1-126-934-11 ELECT 220uF 20.00% 10V
C601 1-164-730-11 CERAMIC CHIP 0.0012uF 10.00% 50V
C602 1-164-730-11 CERAMIC CHIP 0.0012uF 10.00% 50V
C603 1-126-961-11 ELECT 2.2uF 20.00% 50V
C604 1-126-961-11 ELECT 2.2uF 20.00% 50V
C611 1-126-956-91 ELECT 0.1uF 20.00% 50V
C612 1-126-956-91 ELECT 0.1uF 20.00% 50V
C613 1-216-957-91 METAL 33K 1% 0.6W
C614 1-216-957-91 METAL 33K 1% 0.6W
C619 1-126-961-11 ELECT 2.2uF 20.00% 50V
C620 1-126-961-11 ELECT 2.2uF 20.00% 50V
C637 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C638 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C639 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C640 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C641 1-100-229-11 C-CAP, U 6800P-50 K B GRM
C642 1-100-229-11 C-CAP, U 6800P-50 K B GRM
C643 1-128-551-11 ELECT 22uF 20.00% 25V
C644 1-128-551-11 ELECT 22uF 20.00% 25V
C645 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C646 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C647 1-100-229-11 C-CAP, U 6800P-50 K B GRM
C648 1-100-229-11 C-CAP, U 6800P-50 K B GRM
C649 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
CONTROL MAIN
