40
HCD-EP313
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C650 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C651 1-126-961-11 ELECT 2.2uF 20.00% 50V
C652 1-126-961-11 ELECT 2.2uF 20.00% 50V
C660 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C663 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C665 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C666 1-126-935-11 ELECT 470uF 20.00% 10V
C667 1-104-665-11 ELECT 100uF 20.00% 10V
C668 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C670 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C671 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C681 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C682 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C683 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C684 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C700 1-126-947-11 ELECT 47uF 20.00% 25V
C705 1-126-963-11 ELECT 4.7uF 20.00% 50V
C706 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C708 1-126-947-11 ELECT 47uF 20.00% 25V
C709 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C800 1-126-961-11 ELECT 2.2uF 20.00% 50V
C801 1-126-961-11 ELECT 2.2uF 20.00% 50V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-126-935-11 ELECT 470uF 20.00% 16V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C808 1-126-963-11 ELECT 4.7uF 20.00% 50V
C809 1-126-963-11 ELECT 4.7uF 20.00% 50V
C814 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C815 1-126-933-11 ELECT 100uF 20.00% 16V
C816 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C817 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
< CONNECTOR >
CN202 1-793-766-11 CONNECTOR, BOARD TO BOARD 30P
* CN305 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN501 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN502 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN701 1-568-830-11 CONNECTOR, FFC 11P
< DIODE >
D200 6-500-376-01 DIODE 1N4003LES
D201 6-500-378-01 DIODE 1N5402GW(F20)
D202 6-500-378-01 DIODE 1N5402GW(F20)
D203 6-500-378-01 DIODE 1N5402GW(F20)
D204 6-500-378-01 DIODE 1N5402GW(F20)
D205 8-719-991-33 DIODE 1SS133T-72
D206 8-719-991-33 DIODE 1SS133T-72
D207 8-719-991-33 DIODE 1SS133T-72
D208 8-719-991-33 DIODE 1SS133T-72
D209 8-719-991-33 DIODE 1SS133T-72
D210 8-719-991-33 DIODE 1SS133T-72
D211 8-719-991-33 DIODE 1SS133T-72
D212 8-719-991-33 DIODE 1SS133T-72
D213 8-719-991-33 DIODE 1SS133T-72
D403 8-719-109-97 DIODE MTZJ-T-77-6.8B
D404 8-719-991-33 DIODE 1SS133T-72
D405 8-719-109-89 DIODE MTZJ-T-72-5.6B
D501 8-719-991-33 DIODE 1SS133T-72
D602 8-719-109-85 DIODE MTZJ-T-72-5.1B
D603 8-719-109-85 DIODE MTZJ-T-72-5.1B
D801 8-719-923-60 DIODE MTZJ-T-77-9.1A
D802 8-719-991-33 DIODE 1SS133T-72
D803 8-719-923-60 DIODE MTZJ-T-77-9.1A
D804 8-719-991-33 DIODE 1SS133T-72
< FERRITE BEAD >
FB201
FB202
FB401 1-400-297-11 INDUCTOR 0uH
FB701 1-400-297-11 INDUCTOR 0uH
FB710
< IC >
IC200 8-759-231-53 IC TA7805S
IC204 6-704-060-01 IC LA4636
IC601 6-702-895-01 IC BD3881FV
IC800 8-759-167-88 IC NJM4565D
< JACK >
J201 1-793-484-11 JACK, PIN 2P
J202 1-816-219-11 JACK, HEADPHONE
J203 1-536-708-81 TERMINAL BOARD, PUSH (4P) (SPEAKER)
< COIL >
L200 1-400-297-11 INDUCTOR 0uH
L201 1-456-107-11 COIL, K (MDEC)
L202 1-456-107-11 COIL, K (MDEC)
L203 1-456-107-11 COIL, K (MDEC)
L204 1-456-107-11 COIL, K (MDEC)
L205 1-408-117-00 INDUCTOR 10uH
L451 1-456-094-11 COIL, OSC 85KHZ BIAS
< CARBON >
0 PR200 1-249-385-11 CARBON 2.2 5% 1/6W F
0 PR501 1-249-385-11 CARBON 2.2 5% 1/6W F
< TRANSISTOR >
Q200 8-729-230-49 TRANSISTOR 2SC2712L-TE85R
Q205 6-550-333-01 TRANSISTOR 2SC5343GL
Q206 6-550-333-01 TRANSISTOR 2SC5343GL
Q400 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q401 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q402 8-729-024-94 TRANSISTOR 2SB1370-EF
Q403 6-550-296-01 TRANSISTOR 2SA1980G
Q404 6-550-333-01 TRANSISTOR 2SC5343GL
Q405 6-550-333-01 TRANSISTOR 2SC5343GL
Q406 6-550-344-01 TRANSISTOR 2SC3266GR
Q450 8-729-120-28 TRANSISTOR 2SC3052F-T1-LF
Q451 6-550-333-01 TRANSISTOR 2SC5343GL
Q453 6-550-333-01 TRANSISTOR 2SC5343GL
Q454 6-550-333-01 TRANSISTOR 2SC5343GL
Q501 8-729-901-97 TRANSISTOR 2SA1036K-T-147-Q
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
