HCD-EX5
3-11. LID (CD)
3-12. Ornament (Mecha Panel)
2
three
screws
(+BVTT 2.6
×
4
)
1
tension coil spring (CD door
)
4
three
screws
(+BVTT 2.6
×
4
)
6
LID (CD)
5
retainer plate (L)
3
retainer plate (R)
1
four
screws
(+BVTP 2.6
×
8
)
2
ornament (mecha panel)
