19
HCD-EX5
3-17. SPT Pulley Assy, Gear (RT) Assy, Gear (KT), Belt (CDM71)
2
SPT pulley assy
4
gear (KT)
3
gear (RT) assy
SPT pulley assy
1
1
When installing, align the protruded portion of the KT gear with groove of the SPT
pulley assy.
Rotate the SPT pulley assy in the direction of , and remove your hands
at the position where the shaft agrees with the hole shape on the chassis.
5
belt (CDM71 )
