HCD-EX5
3-16. RTR Pulley Assy, RTL Pulley Assy, Belt (CDM71), Belt (Roller) (L)
qf
RTL pulley assy
qg
gear (S1)
qh
belt (CDM71)
qj
belt (ROLLER) (L)
RTL pulley assy
8
c
law
9
c
law
qs
RTR pulley assy
RTR pulley assy
pulley (RTR) assypulley (RTL) assy
5
ENCODER
board
(When installing it, see the ENCODER board item.)
