Sony HCD-EX5 - Page 46

46
HCD-EX5
• Waveforms
3.3 Vp-p
4 IC701 ek (X2)
1 IC101 us (XTAO)
2 IC381 2 FUNCTION:CD
3 IC701 eh (XT2)
5.8 Vp-p
59 ns
1V/DIV,20ns/DIV
4.2 Vp-p
59 ns
31 µ s
1V/DIV,20ns/DIV
1V/DIV,10µs/DIV
1V/DIV,20ns/DIV
3.2 Vp-p
50 ns
IC301 PCM1748E/2K
– MAIN BOARD –
1
3
2
15
14
13
12
11
5
4
6
9
8
10
7
16
ROUT
LOUT
VCC
VDD
DGND
LRCK
DATA
BCK
Serial
Input
Power
System Clock
System Clock
I/F
Zero Detect
DACDAC
Output Amp and
Low-Pass Filter
Output Amp and
Low-Pass Filter
Control
Function
Manager
8x Oversampling Digital Filter
with Function Controller
Enhanced Multi-Level
Deita-Sigma Modurator
Supply
I/F
MCLK
LAT
CLK
DATA
DZFL
DZFR
VCOM
AGND
