3-6. MAIN BOARD, POWER BOARD
qa four screws
(+B 4
× 8)
8 heat sink assy
1 connector 11p (CN801)
a
a
q; MAIN board
2 two screws (+BVTP 3 × 10)
3 screw (+BVTP 3 × 10)
4 holder heat sink
qs silicon shield plate
6 two screws
(+BTP 2.6
× 8)
5 two screws
(+BVTP 3
× 10)
7 two screws
(+BVTP 3
× 10
)
qd TRANSFORMER
board
qf power transformer
9 wire (flat type)
6p (CN306)
