46
HCD-GP6V
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4733-498-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C111 1-126-607-11 ELECT CHIP 47uF 20% 4V
C112 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C113 1-128-995-21 ELECT CHIP 100uF 20% 10V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-128-995-21 ELECT CHIP 100uF 20% 10V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C121 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C122 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C131 1-110-563-11 CERAMIC CHIP 0.068uF 10.00% 16V
C132 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C133 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C150 1-128-394-11 ELECT CHIP 220uF 20% 10V
C151 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C152 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C153 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C156 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C208 1-216-864-11 METAL CHIP 0 5% 1/16W
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C212 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C224 1-115-156-11 CERAMIC CHIP 1uF 10V
C226 1-126-607-11 ELECT CHIP 47uF 20% 4V
C227 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C230 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C231 1-128-394-11 ELECT CHIP 220uF 20% 10V
C250 1-216-864-11 METAL CHIP 0 5% 1/16W
C254 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C258 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C272 1-216-864-11 METAL CHIP 0 5% 1/16W
C273 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C277 1-216-864-11 METAL CHIP 0 5% 1/16W
C310 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C313 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C316 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C354 1-216-864-11 METAL CHIP 0 5% 1/16W
< CONNECTOR >
CN101 1-794-424-11 CONNECTOR, FCC/FPC 16P
CN102 1-784-834-21 CONNECTOR,FFC(LIF(NON-ZIF))23P
CN105 1-784-861-21 CONNECTOR, FFC(LIF(NON-ZIF))9P
< FERRITE BEAD >
FB101 1-216-295-91 SHORT CHIP 0
FB102 1-216-864-11 METAL CHIP 0 5% 1/16W
FB103 1-216-864-11 METAL CHIP 0 5% 1/16W
FB104 1-216-864-11 METAL CHIP 0 5% 1/16W
* FB161 1-469-670-21 FERRITE 0uH
FB201 1-216-295-91 SHORT CHIP 0
FB203 1-216-864-11 METAL CHIP 0 5% 1/16W
FB291 1-216-864-11 METAL CHIP 0 5% 1/16W
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC102 8-759-713-70 IC AN41020A
IC103 8-752-106-21 IC CXA2647N-T4
< JUMPER RESISTOR >
JR4 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L163 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q101 8-729-046-90 TRANSISTOR 2SB970-(TX).S0
< RESISTOR >
R101 1-216-864-11 METAL CHIP 0 5% 1/16W
R102 1-216-835-11 METAL CHIP 15K 5% 1/16W
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
BD
To Next Page
