7-13. PRINTED WIRING BOARD — POWER SECTION —
• See page 19 for Circuit Boards Location.
POWER BOARD
AC VOLTAGE
110V
120V
220V
240V
TO
MAIN BOARD
PN401
(Page 28)
I
AC IN
PT801
POWER TRANSFORMER
PT802
SUB POWER TRANSFORMER
*
NOT REPLACEABLE :
BUILT IN TRANSFORMER
