HCD-GP6V
Connecting Location:
– BD BOARD (Conductor Side) –
IC101
TP7
(VC)
IC103
TP8
(RFAC)
TP6
(RFDC)
TP4
(FE)
TP2
(TE)
Ver 1.1
