HCD-GP6V
Pin No. Pin Name I/O Description
81 O-BIAS O Bias control signal output to the bias oscillation circuit
82 CD O CD power supply control signal output
83 TUNER O Tuner power supply control signal output
84 R-CE O Tuner chip enable signal output to the tuner
85 O-BU-CLK O Clock output to the echo processor (IC504)
86 O-BU-DATA O Data output to the echo processor (IC504)
87 O-BU-STB O Latch signal output to the echo processor (IC504)
88 I-CD DATA I Data input from the video CD circuit
89 VSS2 Ground terminal
90 VDD2 Power supply terminal
91 NC Not used (open)
92 R-ST I Stereo/mono detection signal input from the tuner
93 R-TUNED I Tuner tuned status signal input
94 O-CD ACK O Acknowledge signal output from the video CD circuit
95 NC Not used (open)
96 O-CD STB O Data output to the video CD circuit
97 C-VF ON O Vocal fader on/off control signal output
98 R-DATA O Strobe signal output to the tuner
99 R-COUNT I IF count signal input from the tuner
100 R-CLK O Clock signal output to the tuner
