Sony HCD-GP6V - Page 51

51
HCD-GP6V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C433 1-104-660-91 ELECT CHIP 47uF 20% 16V
C434 1-126-963-11 ELECT 4.7uF 20% 50V
C435 7-611-032-01 WIRE, TINNING COPPER
C501 1-104-660-91 ELECT CHIP 47uF 20% 16V
C502 not supplied
C503 not supplied
C504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C507 not supplied
C508 not supplied
C509 not supplied
C510 1-126-157-11 ELECT 10uF 20% 16V
C511 1-126-157-11 ELECT 10uF 20% 16V
C512 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C513 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C514 1-106-361-00 MYLAR 0.0056uF 5% 100V
C515 1-106-361-00 MYLAR 0.0056uF 5% 100V
C516 1-104-660-91 ELECT CHIP 47uF 20% 16V
C517 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C518 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C519 1-126-962-11 ELECT 3.3uF 20% 50V
C520 1-104-660-91 ELECT CHIP 47uF 20% 16V
C521 not supplied
C522 not supplied
C523 1-165-176-91 CERAMIC CHIP 0.047uF 10.00% 16V
C524 not supplied
C525 not supplied
C527 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C528 7-611-032-01 WIRE, TINNING COPPER
C529 7-611-032-01 WIRE, TINNING COPPER
C530 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C531 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C532 1-104-660-91 ELECT CHIP 47uF 20% 16V
C533 not supplied
C534 not supplied
C535 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C536 1-126-157-11 ELECT 10uF 20% 16V
< CONNECTOR >
* CN201 1-564-520-11 PLUG, CONNECTOR 5P
* CN301 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN302 1-568-838-11 CONNECTOR FFC 21P
CN303 not supplied
CN304 1-784-733-21 CONNECTOR, FFC 11P
CN305 not supplied
CN306 not supplied
* CN401 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-010-32 DIODE UZ-4.7BSA
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-010-32 DIODE UZ-4.7BSA
D402 not supplied
D403 not supplied
D405 8-719-109-89 DIODE RD5.6ESB2
D406 not supplied
D408 not supplied
D409 not supplied
D410 6-500-376-01 DIODE 1N4003LES
D411 8-719-983-35 DIODE MTZJ-T-77-33D
D412 8-719-991-33 DIODE 1SS133T-77
D413 8-719-923-38 DIODE MTZJ-T-77-5.6B
D414 8-719-991-33 DIODE 1SS133T-77
D415 8-719-110-09 DIODE RD8.2ESB3
D416 6-500-335-01 DIODE MC2838
D418 not supplied
D420 8-719-991-33 DIODE 1SS133T-77
D421 8-719-991-33 DIODE 1SS133T-77
D422 8-719-991-33 DIODE 1SS133T-77
D423 8-719-991-33 DIODE 1SS133T-77
D425 8-719-991-33 DIODE 1SS133T-77
D426 8-719-991-33 DIODE 1SS133T-77
D428 8-719-048-55 DIODE MTZJ-T-77-10C
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-991-33 DIODE 1SS133T-77
D505 8-719-991-33 DIODE 1SS133T-77
D506 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB202 7-611-032-01 WIRE, TINNING COPPER
FB301 1-410-396-41 FERRITE 0.45uH
FB302 1-410-396-41 FERRITE 0.45uH
FB303 1-410-396-41 FERRITE 0.45uH
FB304 7-611-032-01 WIRE, TINNING COPPER
FB305 7-611-032-01 WIRE, TINNING COPPER
FB306 7-611-032-01 WIRE, TINNING COPPER
< IC >
IC201 6-704-106-01 IC STK403-040
IC301 6-702-895-01 IC BD3881FV
IC501 6-702-788-01 IC NJM14558MD-TE2
IC502 not supplied
< JACK >
J201 1-793-478-11 JACK, PIN 2P (AUX IN)
J203 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
J204 1-774-785-21 JACK, PIN 1P (SUBWOOFER)
< JUMPER RESISTOR >
JR301 1-216-864-91 METAL CHIP 0 5% 1/16W
< COIL >
L201 1-456-107-11 COIL, AIR-CORE
L202 1-456-107-11 COIL, AIR-CORE
L301 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
L302 not supplied
L303 not supplied
L304 not supplied
L401 1-408-105-31 INDUCTOR 1uH
MAIN
